Air compressor lines

Shop, Garage and Tools

  1. Richard Cranium

    Richard Cranium FBBO Gold Member FBBO Gold Member

    Messages:
    14,191
    Likes Received:
    23343
    Joined:
    Feb 20, 2012
    Location:
    Socialist Republic of Taxachusetts
    Local Time:
    11:44 PM
    When I got my new compressor, the company I bought it from turned me on to "Quick Line air compressor piping. I have the ability & tools to run hard line piping, but measuring, cutting, threading is a major PIA. A Quick Line kit consist of anodized aluminum tubing & plastic fittings, clamps, fitting wrench, pipe reamer & pretty much everything needed to run the lines easily with no muss, no fuss & no mess. It's a bit pricier than iron pipe stock, but not outrageously higher and the blue pipe looks neat. The only parts I need to get are reducing bushings for the end pieces & a short hose to connect to the hose reel. Here's a kit on fleabay...

    http://www.ebay.com/itm/Quick-Line-...ping-Complete-System-Tubing-Kit-/281594223175

    DSCF9315.JPG DSCF9316.JPG DSCF9317.JPG

    • Like Like x 7
    • moparnation74

      moparnation74 FBBO Gold Member FBBO Gold Member

      Messages:
      4,950
      Likes Received:
      7411
      Joined:
      Mar 27, 2014
      Location:
      Texas
      Local Time:
      11:44 PM
      I would choose that over threading pipe any day.....

      Plus it's color correct..Mopar blue fittings!:thumbsup:

      • Like Like x 2
      • WileERobby

        WileERobby Well-Known Member

        Messages:
        3,270
        Likes Received:
        2635
        Joined:
        Sep 15, 2009
        Location:
        State of insanity
        Local Time:
        12:44 AM
        Looks nice, but quick question. Do you have a water separator in line ? What about drip legs for condensation ?

        • Agree Agree x 4
        • conv67bdere

          conv67bdere Super Moderator Staff Member FBBO Gold Member

          Messages:
          4,776
          Likes Received:
          5687
          Joined:
          Aug 18, 2013
          Location:
          Concord, NC
          Local Time:
          12:44 AM
          You can also add an air dryer unit on the air intake too . . .

        • Richard Cranium

          Richard Cranium FBBO Gold Member FBBO Gold Member

          Messages:
          14,191
          Likes Received:
          23343
          Joined:
          Feb 20, 2012
          Location:
          Socialist Republic of Taxachusetts
          Local Time:
          11:44 PM

          Because my compressor has a fan cooled intercooler (aftercooler?) between the compressor & the tank, I was told that I didn't need a water separator, but if it turns out that I do, I'll just cut one in. Regarding drip legs, from what I understand, the main reason for them is to catch any residual metal shavings & crap inside the iron pipe.

          • Agree Agree x 1
          • Stanton

            Stanton Well-Known Member

            Messages:
            548
            Likes Received:
            411
            Joined:
            Aug 8, 2012
            Location:
            ON
            Local Time:
            12:44 AM
            You'd have to be a fool to run iron pipe. Sure, lots of shops have it BUT a) its expensive b) all ends have to be threaded c) it'll rust from the moisture and d) its overkill both in size and strength.

            Standard household copper tubing is a far better choice. Light weight, easy to work with and no rust issues. And for those thinking it won't handle the pressure, it will take 1200 PSI any day of the week!

            That said, I like the new plastic stuff but it wasn't readily available when I did my shop.

            • Like Like x 1
            • Thanks! Thanks! x 1
            • Agree Agree x 1
            • oldbee

              oldbee FBBO Gold Member FBBO Gold Member

              Messages:
              3,704
              Likes Received:
              2737
              Joined:
              Oct 15, 2011
              Location:
              NE Ohio
              Local Time:
              12:44 AM
              The only thing I'd worry about is the vibration affecting the connection after the shutoff valve, but probably a minor issue. Certainly easier to repair anything that happens.Looks good!

            • FJ6AAR

              FJ6AAR FBBO Gold Member FBBO Gold Member

              Messages:
              623
              Likes Received:
              423
              Joined:
              Aug 23, 2012
              Location:
              RUBY SC
              Local Time:
              12:44 AM
              I have the blue Rc. Worth every penny. Really easy to install. All you need is a son inlaw.

              • Like Like x 1
              • Thanks! Thanks! x 1
              • Hanover Mopar

                Hanover Mopar FBBO Gold Member FBBO Gold Member

                Messages:
                558
                Likes Received:
                407
                Joined:
                Nov 12, 2014
                Location:
                Northeast
                Local Time:
                12:44 AM
                That material you used looks like the way to go. I used copper tubing as it was a small job. Only about 30 LF. Holds pressure great for the lift. Compressor only starts every three or four days.

                • Thanks! Thanks! x 1
                • Richard Cranium

                  Richard Cranium FBBO Gold Member FBBO Gold Member

                  Messages:
                  14,191
                  Likes Received:
                  23343
                  Joined:
                  Feb 20, 2012
                  Location:
                  Socialist Republic of Taxachusetts
                  Local Time:
                  11:44 PM

                  Yeah, I thought of that too and I'm going to change that to a rubber hose as soon as I can have one made up.

                  • Like Like x 1
                  • mosquito13

                    mosquito13 FBBO Gold Member FBBO Gold Member

                    Messages:
                    722
                    Likes Received:
                    306
                    Joined:
                    Jun 22, 2010
                    Location:
                    FLA
                    Local Time:
                    11:44 PM
                    Last edited: Jun 19, 2017
                  • Stanton

                    Stanton Well-Known Member

                    Messages:
                    548
                    Likes Received:
                    411
                    Joined:
                    Aug 8, 2012
                    Location:
                    ON
                    Local Time:
                    12:44 AM
                    I gotta say, for the price of that plastic /aluminum kit I could run 3 times the amount in copper !!

                  • bm02tj

                    bm02tj Well-Known Member

                    Messages:
                    1,210
                    Likes Received:
                    644
                    Joined:
                    Jan 27, 2013
                    Location:
                    BC Canada
                    Local Time:
                    9:44 PM
                    Pvc is not allowed in BC as when cold or impacted it will shatter
                    our work safe will shut a shop down that is using it
                    in a warm climate with no sun exposure it will last awhile but I would not use it my self

                  • 1976 charger sport

                    1976 charger sport New Member

                    Messages:
                    2
                    Likes Received:
                    1
                    Joined:
                    May 24, 2016
                    Local Time:
                    11:44 PM
                    i used 1/2 inch d.o.t. air brake tubing in a continuous loop fed on both ends by compressor.

                    • Like Like x 1
                    • steve from staten island

                      steve from staten island FBBO Gold Member FBBO Gold Member

                      Messages:
                      3,364
                      Likes Received:
                      3092
                      Joined:
                      Sep 24, 2012
                      Location:
                      staten island,ny
                      Local Time:
                      12:44 AM
                    • threewood

                      threewood Well-Known Member

                      Messages:
                      1,916
                      Likes Received:
                      1487
                      Joined:
                      May 30, 2014
                      Location:
                      Yuma, AZ
                      Local Time:
                      9:44 PM
                      I like my copper...

                      • Agree Agree x 1
                      • Stanton

                        Stanton Well-Known Member

                        Messages:
                        548
                        Likes Received:
                        411
                        Joined:
                        Aug 8, 2012
                        Location:
                        ON
                        Local Time:
                        12:44 AM
                        steel rusts - copper doesn't

                      • Richard Cranium

                        Richard Cranium FBBO Gold Member FBBO Gold Member

                        Messages:
                        14,191
                        Likes Received:
                        23343
                        Joined:
                        Feb 20, 2012
                        Location:
                        Socialist Republic of Taxachusetts
                        Local Time:
                        11:44 PM
                        This....


                        looks like he beginning of this.........



                        • Like Like x 3
                        • WileERobby

                          WileERobby Well-Known Member

                          Messages:
                          3,270
                          Likes Received:
                          2635
                          Joined:
                          Sep 15, 2009
                          Location:
                          State of insanity
                          Local Time:
                          12:44 AM
                        • cornpicker

                          cornpicker Active Member

                          Messages:
                          29
                          Likes Received:
                          15
                          Joined:
                          Mar 29, 2013
                          Location:
                          Bedford, Ohio
                          Local Time:
                          12:44 AM
                          R C , It's a good practice to connect your compressor to the wall with a piece of flexable hose as the air compressor vibrates. Killer shop ! I love it !
