727 kickdown question

Engine, Trans & Driveline

  1. 104thLRSD

    104thLRSD Member

    Messages:
    5
    Likes Received:
    2
    Joined:
    Dec 27, 2019
    Location:
    Pennsylvania
    Local Time:
    2:28 PM
    Hello all.

    I am pretty new to the forum and the first time I have ever posted anything. I had a question and figured this the best place to find an answer. I bought a 68 GTX over a year ago. I have no idea what the previous owners did to the car and have limited history. I have been doing a lot of things here and there to improve it while keeping it as close to stock as possible. This is my first Mopar muscle car and I have never previously owned anything with a 440 or a 727 transmission. Someone had installed a shift kit in the transmission. The car starts out in 2nd gear and shifts to 3rd flawlessly. 1st will engage if I manually shift into that gear. When I drive the car at highway speeds and crack the throttle it accelerates fine but does not downshift. Is that normal? I feel like it is not kicking down. All the linkage is in place. Is it out of adjustment? or is it not adjustable because of the shift kit?

  2. vance.dykes

    vance.dykes Well-Known Member

    Messages:
    415
    Likes Received:
    354
    Joined:
    Sep 22, 2017
    Location:
    florida
    Local Time:
    2:28 PM


    go to mymopar.com and down load the manual for the car the adjustments will be in thre

    • Agree Agree x 2
    • Demonic

      Demonic Well-Known Member

      Messages:
      751
      Likes Received:
      626
      Joined:
      Jun 5, 2017
      Location:
      Over the hills, far away
      Local Time:
      2:28 PM
      That's bad. Govenor pressure issue or maybe the valve body. It should start in first. The lack of kickdown at high speeds is not unusual for a 70 and earlier stock transmission. Do you have a large face 300 psi gauge and about 5' of high pressure hose with 1/8' mpt fittings? Pressure tests per the factory can tell you a lot.

      • Agree Agree x 1
      • Fran Blacker

        Fran Blacker FBBO Gold Member FBBO Gold Member

        Messages:
        7,242
        Likes Received:
        6792
        Joined:
        Sep 23, 2016
        Location:
        Connecticut
        Local Time:
        2:28 PM
        Have you tried putting gear shift in different positions? Shift pattern could be different than stock.
        Need pictures of your car before the barbarians come for you.:lol:
        :mob::xscuseless:

      • 104thLRSD

        104thLRSD Member

        Messages:
        5
        Likes Received:
        2
        Joined:
        Dec 27, 2019
        Location:
        Pennsylvania
        Local Time:
        2:28 PM
        Thank you I do have a pressure gauge. And I mis-spoke. It shifts from 1st to 3rd skipping 2nd.

        IMG_2955.jpg IMG_3055.jpg IMG_3056.jpg

        • Like Like x 2
        • Demonic

          Demonic Well-Known Member

          Messages:
          751
          Likes Received:
          626
          Joined:
          Jun 5, 2017
          Location:
          Over the hills, far away
          Local Time:
          2:28 PM
          Oh. That makes a big difference. Most likely is the kickdown band needs adjustment. Tighten to 72 inch-pounds and back off two turns.

          Nice looking GTX!

          • Agree Agree x 1
          • 104thLRSD

            104thLRSD Member

            Messages:
            5
            Likes Received:
            2
            Joined:
            Dec 27, 2019
            Location:
            Pennsylvania
            Local Time:
            2:28 PM
            Thanks Man. Much appreciated...

          • Lefty71

            Lefty71 FBBO Gold Member FBBO Gold Member

            Messages:
            1,451
            Likes Received:
            1555
            Joined:
            Mar 8, 2018
            Location:
            Ohio
            Local Time:
            2:28 PM
            Reading through what you've posted there's an issue for sure. Tough to get (or give) a definative answer because the term 'shift kit' can mean so many potential modifications from so many potential manufacturers. I guess if it were me, I'd start with all adjustments as if it were factory, whilst noting the current settings in a log, and see what the results are. Also, maybe worthwhile if possible to question the previous owner on specific mods done. If all else fails, pull the pan and possibly the valve body and see if you can figure out whats been done and whos parts are in there. Nice looking car, BTW.

          • Dipstick

            Dipstick Well-Known Member

            Messages:
            579
            Likes Received:
            539
            Joined:
            Oct 26, 2018
            Location:
            Out West
            Local Time:
            11:28 AM
            A '68 won't kickdown at part throttle, only when the throttle is floored. At highway speeds maybe not at all, depends on the speed.

            • Agree Agree x 1
            • 104thLRSD

              104thLRSD Member

              Messages:
              5
              Likes Received:
              2
              Joined:
              Dec 27, 2019
              Location:
              Pennsylvania
              Local Time:
              2:28 PM
              Thank you all for the replies and advice. I bought the car through a third party and the previous owner was zero help and wouldn't even entertain a phone call. (I didn't realize this until after I wrote the check) I have been trying to figure out everything by myself and correcting things along the way. When I first bought the car I took it to a local transmission shop that still works on older stuff. That is who told me a shift kit had been installed. Transmissions and rear differentials are above my skill level. I am gonna take all of your advice and make the adjustments to factory and go from there. I found a vin stamp on the transmission and am pretty sure it was from a 69 Polara.

            • dvw

              dvw Well-Known Member

              Messages:
              4,642
              Likes Received:
              6403
              Joined:
              Feb 16, 2010
              Location:
              waterford mi
              Local Time:
              2:28 PM
              If it absolutely has no 2nd gear. I would drop the pan. Hard to believe the KD band is loose enough to have no 2nd gear at all. If the band is worn that far, chances are its close to metal. It is possible the servo piston is cracked or the strut may have fallen out. These are accessible in the car. If you drop the valve body you can air check the KD servo. If everything is is intact loosen the band adjustment lock nut. Count how many flats of the adjuster it takes to snug the adjuster down. If it takes more than 3 1/2 -4 the band may be excessively worn. If the throttle pressure linkage has been incorrectly adjusted the band is the 1st to sustain damage.
              Doug

            • wyrmrider

              wyrmrider Well-Known Member

              Messages:
              2,135
              Likes Received:
              835
              Joined:
              Aug 26, 2014
              Location:
              los angeles
              Local Time:
              11:28 AM
              back to the valve body
              locate a later valve body with part throttle kickdown
              then build it with the Transgo reprogramming kit do level 2
              this is a DIY
              then swap after you find out what your big problem is
              do have a gasket and filter and some ATF+4
              the OEM oil for the early years is no longer available and ATF +4 is good stuffand much better anyway
              does your converter have a drain?
              cheers

            • 104thLRSD

              104thLRSD Member

              Messages:
              5
              Likes Received:
              2
              Joined:
              Dec 27, 2019
              Location:
              Pennsylvania
              Local Time:
              2:28 PM
              I can manually upshift and downshift into 2nd gear. It skips second if the car is in drive. Goes from 1st to 3rd. Doesn't seam to slip or shift hard.

            • dvw

              dvw Well-Known Member

              Messages:
              4,642
              Likes Received:
              6403
              Joined:
              Feb 16, 2010
              Location:
              waterford mi
              Local Time:
              2:28 PM
              If manual 2nd applies then the servo is able to clamp the band. I'd be looking for a stuck 1/2 shift valve.
              Doug
