An Addition to Your Shop References

[cr8crshr]

I have commented here on numerous occasions about the lack of reference material a lot here seem to not have in their possession. Items such as FSM, Wiring Schematics, etc. For those looking, here is the best place for the Wiring Schematics I am referring to. Only thing I will say is, "GET ONE!!!! Best 18.00 bucks I have ever spent and it has been the very first thing I have purchase after acquiring a car or truck to work on. Hope this will help you all out...cr8crshr/Tuck:blob1::blob1::blob1:

http://www.classiccarwiring.com/



[themechanic]

You're exactly right. Get the largest one. It's a must have.

Posted via Topify on Android



[super-bee_ski]

Thanks for this great post cr8crshr

A MUST HAVE..



[Cranky]

Those don't do much good for someone who is partially color blind (shade blind).......or worse yet, completely color blind.



[69a100]

Those don't do much good for someone who is partially color blind (shade blind).......or worse yet, completely color blind.

But they can still follow a line and figure it out.



[cr8crshr]

Those don't do much good for someone who is partially color blind (shade blind).......or worse yet, completely color blind.

Cranky that sucks Man!!! At least it will give a clearer picture to trace and trouble shoot circuitry...cr8crshr/Tuck



[TekHousE]

I have one of these, the large one! It is awesome!



[hunt2elk]

I have one for each of my cars. I had them enlarge mine to fit on 2 - 8.5 x 11 laminated sheets set side by side. Works great for old eyes like mine.



[idrivemopar]

I agree 100%, very valuable to have as much information as possible.

Here is my small collection, the Motor and I have had since the 80's, the others I picked up before starting my restoration, and the service manuals have great schematics.



[Cranky]

But they can still follow a line and figure it out.

Cranky that sucks Man!!! At least it will give a clearer picture to trace and trouble shoot circuitry...cr8crshr/Tuck

When most of the lines all look to be the same color, they look like a bowl of spaghetti and when the wiring in the car is old and faded, it gets even worse. I can do the basics....the harder stuff goes to a buddy of mine that can see even the faded stuff lol
