Distributor clearance issue

Engine, Trans & Driveline

  1. Green72

    Green72 Well-Known Member

    Messages:
    72
    Likes Received:
    53
    Joined:
    Mar 7, 2019
    Location:
    52314
    Local Time:
    6:47 PM
    1816B72A-7898-4FC5-A341-A3601DF8CA1F.jpeg 5E2FE30D-9CE8-4A02-9234-DF5750DE320C.jpeg 440 source fabricated valve covers and MSD distributor. I have ground the valve cover flange as far as I think I can. I can now install the distributor but it has very little room. I can install the cap and rotate the distributor but the spark plug wire ends contact the valve cover. Should I be concerned about wires in contact with the valve covers?
    Any suggestions to remedy my situation would be great!

  2. gdrill

    gdrill Just enjoying "B"-ing here FBBO Gold Member

    Messages:
    3,191
    Likes Received:
    4867
    Joined:
    May 29, 2013
    Location:
    Stuck in the past, just North of Montana....
    Local Time:
    5:47 PM
    Different combination of parts. :(

    • Agree Agree x 4
    • 493 Mike

      493 Mike FBBO Gold Member FBBO Gold Member

      Messages:
      2,766
      Likes Received:
      2919
      Joined:
      Dec 25, 2011
      Location:
      White Cloud, MI
      Local Time:
      7:47 PM
      I don't think you will get any spark jump with all new components in the secondary ignition system.
      Mike

      • Agree Agree x 2
      • Dan64

        Dan64 Well-Known Member

        Messages:
        938
        Likes Received:
        956
        Joined:
        Dec 27, 2018
        Location:
        South Jersey
        Local Time:
        7:47 PM
        What heads are you running?.

      • boltupal

        boltupal Well-Known Member

        Messages:
        156
        Likes Received:
        25
        Joined:
        Apr 1, 2013
        Location:
        new york
        Local Time:
        7:47 PM
        When that aluminum valve cover gets hot. Its going to break that Dist. cap.

      • 91r/t

        91r/t Well-Known Member

        Messages:
        2,177
        Likes Received:
        2680
        Joined:
        May 7, 2011
        Location:
        Buffalo, NY
        Local Time:
        6:47 PM
        See this quite a bit with aftermarket valve covers and the MSD distributor. Seems they are a bit more bulky than a stock distributor.

        • Agree Agree x 3
        • AR67GTX

          AR67GTX Well-Known Member

          Messages:
          1,266
          Likes Received:
          616
          Joined:
          Jan 28, 2012
          Location:
          Arkansas
          Local Time:
          6:47 PM
          You might get spark jump through the boots. A friend with a 69 Hemi ran a MSD for awhile and the cap/boots rested against the hood air intake pan which has a metal strip reinforcement for the screws. He was blowing through a distributor wire boot about once a week and shorting to the metal strip. We would find a small, pin head size hole burned through the boot each time. He finally changed to an FBO distributor that was shorter.

        • Green72

          Green72 Well-Known Member

          Messages:
          72
          Likes Received:
          53
          Joined:
          Mar 7, 2019
          Location:
          52314
          Local Time:
          6:47 PM
          Trickflow 240s

          • Like Like x 1
          • 440 Charger

            440 Charger FBBO Gold Member FBBO Gold Member

            Messages:
            270
            Likes Received:
            104
            Joined:
            Aug 1, 2020
            Location:
            naples Fl
            Local Time:
            7:47 PM
            Aftermarket always has issues. Remember I would bet lots of Engineers were involved in the motor and the distributor.

            • Agree Agree x 1
            • andyf

              andyf Well-Known Member

              Messages:
              826
              Likes Received:
              1267
              Joined:
              Jul 21, 2012
              Location:
              Oregon
              Local Time:
              4:47 PM
              First rule of hot rodding: Not everything fits with everything.

              • Agree Agree x 3
              • Like Like x 1
              • Green72

                Green72 Well-Known Member

                Messages:
                72
                Likes Received:
                53
                Joined:
                Mar 7, 2019
                Location:
                52314
                Local Time:
                6:47 PM
                I am leaning towards modifying the valve cover. Just have to figure out how much room I have on the rocker

                • Agree Agree x 1
                • andyf

                  andyf Well-Known Member

                  Messages:
                  826
                  Likes Received:
                  1267
                  Joined:
                  Jul 21, 2012
                  Location:
                  Oregon
                  Local Time:
                  4:47 PM
                  Looks like the valve covers are powder coated though? You can cut them up and modify the corner but it might not look great when you're done. Bottom line is that whoever built those valve covers did a poor job. They should've known that MSD distributors don't fit. The valve cover might have been designed to work with the 440 Source distributor.
                  When I designed my own valve covers I made sure they worked with my distributor.
                  DSC_3420 (Large).JPG

                  • Like Like x 2
                  • Green72

                    Green72 Well-Known Member

                    Messages:
                    72
                    Likes Received:
                    53
                    Joined:
                    Mar 7, 2019
                    Location:
                    52314
                    Local Time:
                    6:47 PM
                    I powder coated them, so I can fix that. I should have mocked it up!! Seems like 440 source could mention it.

                  • Dan64

                    Dan64 Well-Known Member

                    Messages:
                    938
                    Likes Received:
                    956
                    Joined:
                    Dec 27, 2018
                    Location:
                    South Jersey
                    Local Time:
                    7:47 PM
                    I thought maybe, i have T.F. 270's and they seem to put the valve cover closer to the dist. When my engine was dynoed we used the builder's valve covers and he noted that this was the most he had to clearance them . I'll take the trade off,lol.

                  • Green72

                    Green72 Well-Known Member

                    Messages:
                    72
                    Likes Received:
                    53
                    Joined:
                    Mar 7, 2019
                    Location:
                    52314
                    Local Time:
                    6:47 PM
                    Thanks for all the input everyone.
                    Andy F your book has been invaluable.
                    I will make it work one way or the other

                  • 70rcode

                    70rcode Well-Known Member

                    Messages:
                    123
                    Likes Received:
                    18
                    Joined:
                    Jun 28, 2017
                    Location:
                    Usa
                    Local Time:
                    7:47 PM
                    Depending on the rocker arm clearance, maybe fab up an Internal corner weld bead & grind off the extenal interfering bead material + "massage" hammer to clearance fit...

                    • Like Like x 1
                    • Green72

                      Green72 Well-Known Member

                      Messages:
                      72
                      Likes Received:
                      53
                      Joined:
                      Mar 7, 2019
                      Location:
                      52314
                      Local Time:
                      6:47 PM
                      That’s kinda what I’m thinking

                    • dvw

                      dvw Well-Known Member

                      Messages:
                      5,232
                      Likes Received:
                      7394
                      Joined:
                      Feb 16, 2010
                      Location:
                      waterford mi
                      Local Time:
                      7:47 PM
                      Same distributor with my Indy 440-25 manifold. I ground the intake and the lip off the cap. Wires touch the valve cover. 7 years 700 +passes at 15-1 compression. Never a misfire issue.
                      Doug


                      • Like Like x 1
                      • Green72

                        Green72 Well-Known Member

                        Messages:
                        72
                        Likes Received:
                        53
                        Joined:
                        Mar 7, 2019
                        Location:
                        52314
                        Local Time:
                        6:47 PM
                        I made it work. Took a little here and a little there and then some shaping with a hammer. I'm comfortable with it now
                        Thanks again everyone

                        • Like Like x 1
                        • Fran Blacker

                          Fran Blacker FBBO Gold Member FBBO Gold Member

                          Messages:
                          8,581
                          Likes Received:
                          8195
                          Joined:
                          Sep 23, 2016
                          Location:
                          Connecticut
                          Local Time:
                          7:47 PM
                          Pictures???
