Manuel to Power steering

Brakes, Steering & Suspension

  1. relam

    relam Well-Known Member

    Messages:
    133
    Likes Received:
    53
    Joined:
    Nov 14, 2015
    Location:
    Chino Hills
    Local Time:
    10:24 PM
    Is it possible to convert a manual steering to power on a 67 charger ?

  2. 65-440

    65-440 Well-Known Member

    Messages:
    3,138
    Likes Received:
    2630
    Joined:
    Dec 2, 2009
    Location:
    virginia beach, va
    Local Time:
    3:24 AM
    Yes

  3. relam

    relam Well-Known Member

    Messages:
    133
    Likes Received:
    53
    Joined:
    Nov 14, 2015
    Location:
    Chino Hills
    Local Time:
    10:24 PM
    Oh perfect thanks

  4. 727

    727 Well-Known Member

    Messages:
    538
    Likes Received:
    416
    Joined:
    May 18, 2015
    Location:
    Mississippi
    Local Time:
    12:24 AM
    I did on my ‘66 charger. Bought a power steering box online and was never happy with it. I picked up a rack and pinion system and didn’t realize what I was missing.

  5. moes

    moes Well-Known Member

    Messages:
    901
    Likes Received:
    1257
    Joined:
    Dec 18, 2015
    Location:
    CANADA
    Local Time:
    1:24 AM
    yea you can do it. You will need P/S pump, P/S hoses, P/S gear box, P/S pitman arm and a P/S coupler to. You will need to make the manual steering shaft shorter. Take the coupler off & measure the distance the pin in the shaft is from the end. Then you cut 2.5" off the shaft (just going from my memory, check the distance to be sure), measure for the pin & drill a new hole for it.

    I believe you will need the P/S coupler body, Manual couples have different spline sizes then P/S couplers

  6. dadsbee

    dadsbee FBBO Gold Member FBBO Gold Member

    Messages:
    9,561
    Likes Received:
    23040
    Joined:
    Jan 29, 2018
    Location:
    Midland Ontario, Canada
    Local Time:
    1:24 AM
    Don't do it.... :poke:

    • Agree Agree x 2
    • Green72

      Green72 Well-Known Member

      Messages:
      119
      Likes Received:
      90
      Joined:
      Mar 7, 2019
      Location:
      52314
      Local Time:
      12:24 AM
      Check out Borgeson

      • Agree Agree x 1
      • MoparLeo

        MoparLeo NRA BENEFACTOR LEVEL LIFE MEMBER FBBO Gold Member

        Messages:
        1,418
        Likes Received:
        1237
        Joined:
        Nov 24, 2015
        Location:
        Moreno Valley, So California
        Local Time:
        10:24 PM
        Having "Manuel" do the steering is racist...But manual steering is still ok.

        • Like Like x 5
        • Nate S

          Nate S Well-Known Member

          Messages:
          1,084
          Likes Received:
          1070
          Joined:
          Apr 24, 2020
          Location:
          Connecticut
          Local Time:
          1:24 AM
          Did it in my ‘64 Sport Fury, much better. All opinions of course, remember the stock setup is the “arms injected with novocaine” power steering. I picked up a good box and correct shorter steering column. Had the pump from an engine I picked up. A bit of work but not too bad, no new pittman arm, I’m pretty sure they are the same. Anyway, easy enough. For me parking and low speed is better and curvy roads are better (3.5:1 instead of 5.5:1) no more hand over hand for a regular road. Can drink my coffee on my way to work.

        • 67charger383

          67charger383 Well-Known Member

          Messages:
          1,564
          Likes Received:
          2930
          Joined:
          Dec 13, 2019
          Location:
          Maryland
          Local Time:
          1:24 AM
          =http%3A%2F%2Fi.kinja-img.com%2Fgawker-media%2Fimage%2Fupload%2Fs--CwUFmyV7--%2F18q06oe6y7o70jpg.jpg

          • Like Like x 2
          • Rainy day auto

            Rainy day auto Well-Known Member

            Messages:
            99
            Likes Received:
            177
            Joined:
            Sep 16, 2019
            Location:
            Colorado
            Local Time:
            11:24 PM
            Dang, I'm trying to go power to manual on my GTX.

            I like simple cars

            • Like Like x 1
            • 67charger383

              67charger383 Well-Known Member

              Messages:
              1,564
              Likes Received:
              2930
              Joined:
              Dec 13, 2019
              Location:
              Maryland
              Local Time:
              1:24 AM
              I'm converting my '67 charger to manual steering.

              Don't want the street machine to steer like a boat!

            • origcharger

              origcharger Well-Known Member

              Messages:
              99
              Likes Received:
              72
              Joined:
              Sep 7, 2008
              Location:
              Iowa
              Local Time:
              12:24 AM
              I have a 67 Charger with power steering and a 66 Charger that I ended up converting to power steering, both have Borgeson boxes. While the simplicity of the manual was appealing and may be tolerable with skinny OE like tires, 235 60 tires made low speed maneuvering more of a struggle than I wanted.

              • Agree Agree x 1
              • coronet68mx

                coronet68mx FBBO Gold Member FBBO Gold Member

                Messages:
                3,956
                Likes Received:
                7695
                Joined:
                Sep 18, 2014
                Location:
                Uruapan, Michoacán, México
                Local Time:
                12:24 AM
                Hey!!!! I resemblance that "Manuel"comment":)
