Max Wedge pistons

1962 - 1965 Mopars

  1. Daytona Jim

    Daytona Jim Well-Known Member

    Messages:
    107
    Likes Received:
    111
    Joined:
    Jun 26, 2015
    Location:
    Napa California
    Local Time:
    9:43 AM
    Building a 426 Max Wedge 11:1 engine, I'm not finding pistons listed with any of the big piston mfgs. Does anybody know of a supplier for these? Thanks, Jim.

  2. Polara426

    Polara426 Well-Known Member

    Messages:
    257
    Likes Received:
    122
    Joined:
    May 3, 2010
    Location:
    norteast ohio
    Local Time:
    11:43 AM
    No one makes a on the shelf good piston for the 4.25 bore for that stroke guy's will tell you to build a 440 as the piston selection is much better. If you have to build a 426 get custom pistons from a good source it will be cheaper in the long run. There is a company that sells factory style cast pistons about 10 to 1 but they are boulders I ended up putting in lighter pins and spending to much for heavy metal to balance the crank. Every once an awhile you see factory 11 to one forged pistons come up but they usually are not cheap.

    • Agree Agree x 3
    • 6t4polara

      6t4polara Well-Known Member

      Messages:
      667
      Likes Received:
      251
      Joined:
      Mar 11, 2011
      Location:
      Mi.
      Local Time:
      11:43 AM
      Hughes engines lists 426 wedge pistons.

    • lewtot184

      lewtot184 Well-Known Member

      Messages:
      4,666
      Likes Received:
      2952
      Joined:
      Aug 21, 2011
      Location:
      indianapolis
      Local Time:
      12:43 PM
      the original 11:1 pistons were made by TRW. to my knowledge they haven't been reproduced in decades.

    • 67BELRO

      67BELRO Well-Known Member

      Messages:
      129
      Likes Received:
      32
      Joined:
      Mar 13, 2015
      Location:
      viroqua Wi 54665
      Local Time:
      11:43 AM
      You run a 6.9 eagle rod with a 383 11.0 to 1 KB piston. are you can send me a PM and I can sell you some 64 parts

    • Yournewtreasureawaits

      Yournewtreasureawaits Well-Known Member

      Messages:
      48
      Likes Received:
      15
      Joined:
      Dec 25, 2013
      Location:
      Suisun City CA
      Local Time:
      9:43 AM
      Jim,

      I think I have a set of LC pistons TRW's

    • moparsquid

      moparsquid FBBO Gold Member FBBO Gold Member

      Messages:
      341
      Likes Received:
      138
      Joined:
      Sep 9, 2010
      Location:
      spring valley ,ca.
      Local Time:
      9:43 AM
      the last time I looked I think bob mazolini had them for sale

    • 63SPF

      63SPF MOPAR 4 LIFE ! MOPAR OR BUST ! PLYMOUTH'S RULE ! FBBO Gold Member

      Messages:
      1,266
      Likes Received:
      1371
      Joined:
      Oct 26, 2014
      Location:
      Kona , Hawaii
      Local Time:
      6:43 AM
      Bob, is who I bought mine from

    • stage3

      stage3 Well-Known Member

      Messages:
      539
      Likes Received:
      717
      Joined:
      Mar 3, 2016
      Location:
      california
      Local Time:
      9:43 AM
      I also have the same problem locating pistons other than custom units...6.90 eagle rods????with 383 pistons...I looked at eagles website and did not see a rod like that???


      • Like Like x 1
      • stage3

        stage3 Well-Known Member

        Messages:
        539
        Likes Received:
        717
        Joined:
        Mar 3, 2016
        Location:
        california
        Local Time:
        9:43 AM
        are those forged flat tops?what bore..looked for a PM button here,did not see it..thanks..

      • 1962polara

        1962polara Well-Known Member

        Messages:
        924
        Likes Received:
        802
        Joined:
        Mar 15, 2013
        Location:
        alaska
        Local Time:
        2:43 AM
        PM=conversations

      • stage3

        stage3 Well-Known Member

        Messages:
        539
        Likes Received:
        717
        Joined:
        Mar 3, 2016
        Location:
        california
        Local Time:
        9:43 AM
        got it...thanks..

      • stage3

        stage3 Well-Known Member

        Messages:
        539
        Likes Received:
        717
        Joined:
        Mar 3, 2016
        Location:
        california
        Local Time:
        9:43 AM
        PM sent thanks..

      • PolyJon

        PolyJon Active Member

        Messages:
        43
        Likes Received:
        20
        Joined:
        Jan 14, 2016
        Location:
        Sheppey
        Local Time:
        11:43 AM
        Thought about flat top 383 pistons with a hemi 6.860 rod too.
        Open out the small end to 1.094 from 1.031...:thumbsup:

      • fbs63

        fbs63 Well-Known Member

        Messages:
        268
        Likes Received:
        178
        Joined:
        Feb 5, 2017
        Location:
        Lowell, Indiana
        Local Time:
        11:43 AM
        Diamond pistons will change bore size on a shelf piston. Just get a 440 piston and change the bore size to what you need.

      • Rolling Thunder

        Rolling Thunder Well-Known Member

        Messages:
        626
        Likes Received:
        309
        Joined:
        Sep 11, 2009
        Location:
        Trenton, IL
        Local Time:
        11:43 AM
        Cleared inbox out. Sorry can’t help right now. Sold these back in 2016 I think.

      • PolyJon

        PolyJon Active Member

        Messages:
        43
        Likes Received:
        20
        Joined:
        Jan 14, 2016
        Location:
        Sheppey
        Local Time:
        11:43 AM
        Many thanx for the reply R/T.
        It’s surprising how few stock MW 413 pistons have survived.
        Polyjon

      • 33 IMP

        33 IMP Well-Known Member

        Messages:
        5,260
        Likes Received:
        7084
        Joined:
        Dec 21, 2017
        Location:
        taxifornia,soon 2b Arizona.
        Local Time:
        9:43 AM
        Icon makes a premium piston for a mopar 3.75 stroke, 4.25 (plus whatever oversize) bore, IC689, and IC690. I suspect they are intended for stroker 383, but maybe with rb length rods.....?
        Edit: also a .070 over 426 is a standard bore 440. What is your current bore size? What do you want it to be?
        Edit: looks like the 690 is a dished piston, the 689 is a small dome.

        Last edited: Dec 3, 2020
      • Dipstick

        Dipstick Well-Known Member

        Messages:
        932
        Likes Received:
        898
        Joined:
        Oct 26, 2018
        Location:
        Out West
        Local Time:
        9:43 AM
        Are you building the engine to race or show? If it's only to show, you might consider a lower compression ratio so you can run unleaded pump gas.

        • Agree Agree x 1
        • coloradodave

          coloradodave FBBO Gold Member FBBO Gold Member

          Messages:
          3,661
          Likes Received:
          3030
          Joined:
          Jun 1, 2011
          Location:
          Lincoln, CA
          Local Time:
          9:43 AM
          FYI, 4 year old thread...

          • Agree Agree x 2
