What is the best way to identify all of the part names?

coloradodanny

Member
Local time
5:51 PM
Joined
Oct 17, 2022
Messages
20
Reaction score
25
Location
colorado springs
1970 Dodge Charger:
I’ve got her in the garage. Shop is set up. I’m ready to go. I need a great reference to all the parts names on her. There are so many! I know the basics, but I’m getting overwhelmed when I’m sourcing a part to understand all the support items needed to get the job done. Im starting with the replacement of the rear frame rails. As many of you know, this is a long road, but I’m loving every moment of it. My plan is to use my skills whenever possible and then have a pro mentor (you guys) when I’m stuck. Thank you to all who have reached out already. I’m grateful to have this b body fam on my team.



















themechanic

Oklahoma is OK
FBBO Gold Member
Local time
6:51 PM
Joined
Nov 11, 2012
Messages
16,401
Reaction score
19,020
Location
Moore, Oklahoma
Get an assembly manual (hard to find), a parts manual and a factory service manual.

I don't know about the accuracy of aftermarket restoration books but folks on FBBO will know which ines are good and which to avoid.

Best of luck.


68Moparmaniac

Well-Known Member
Local time
5:51 PM
Joined
Jan 18, 2019
Messages
1,345
Reaction score
2,582
Location
Utah
Woof, rear frame rails are toast.. be ready to open up that wallet brother. Good news is there are a lot of parts available for these 2 gen Chargers. Good luck with your new mistress :thumbsup:


MoparLeo

NRA BENEFACTOR LEVEL LIFE MEMBER
FBBO Gold Member
Local time
4:51 PM
Joined
Nov 24, 2015
Messages
2,090
Reaction score
2,001
Location
Moreno Valley, So California
Honestly, you have a LOT of work in front of you and will need more than advice. Have it towed to the AMD installation center and have it done where they have the proper jigs, every part that is available and the experience to know just how it all goes together.
It won't be cheap but it will be as right as it can get
Higher resale in the future as well.
Then you can do all the "easy" stuff like body, paint, wiring, brakes, suspension, engine, trans, interior etc...


Bighouse

Well-Known Member
Local time
7:51 PM
Joined
Mar 28, 2020
Messages
1,054
Reaction score
1,692
Location
New York
Order everything and return what you don’t need, because you need a lot.
:drinks:


66 Sat

FBBO Gold Member
FBBO Gold Member
Local time
6:51 PM
Joined
Apr 26, 2015
Messages
1,504
Reaction score
3,075
Location
Australia
Think carefully before you start.
That car is in a bad way and would be a handful for an experienced enthusiast with all the tools and skills. Think years of work, not months.
Maybe better to sell and start with something that just needs cosmetic bodywork and some mechanical?
Just friendly advice from someone who's made similar mistakes in the past...


Bighouse

Well-Known Member
Local time
7:51 PM
Joined
Mar 28, 2020
Messages
1,054
Reaction score
1,692
Location
New York
In all seriousness, that car is going to need to go on a frame jig to make sure everything installs nicey nice. Unless you really, really know what your doing.

What’s your skill level? This is going to take some serious auto body knowledge and welding/fab skills. And that’s just to replace what’s rusted away.


chtampa

FBBO Gold Member
FBBO Gold Member
Local time
7:51 PM
Joined
Nov 24, 2013
Messages
3,827
Reaction score
4,749
Location
Tampa, FL
Isn't there an AMD place that has a all included price to get a solid car back?


hunt2elk

FBBO Gold Member
FBBO Gold Member
Local time
6:51 PM
Joined
Jul 15, 2009
Messages
9,477
Reaction score
9,554
Location
WI
I'm not condemning your enthusiasm one bit, BUT you have one heck of a project there. You need to access your skills and the $ it will cost to rebuild that one to determine if it is worth it to you. How good of a welder and metal fab guy are you? Mopar4Don has a restoration thread on his Charger you should read through. His was in better shape than this one, and he has been working on his for 10 years now...


coloradodanny

Member
Local time
5:51 PM
Joined
Oct 17, 2022
Messages
20
Reaction score
25
Location
colorado springs
Thanks for all the good advice.
I’ve been self employed for twenty years and I’m in a position where I have lots of free time. I understand the complexity of the task. My goal is to have a hobby that will give me something to do. Being young and semi retired can be a curse if you don’t stay busy. I Have a veteran body shop for all metal installs. I just want to do all the prep work. I know my car is rough but I’ve owned finished cars that someone else built and they felt soulless to me. Cool to own, but didn’t fit my personality. I also have five kids that are very excited to have this project. We’ve had Hellcats and Humvee’s, but this one is their favorite. It’s my favorite car of all time. I’m truly grateful for your responses. If I was easily scared by big task, I would’ve never stared a successful business. After all I was a high school dropout headed for prison or death. At least that’s what the adults in my life told me.


chtampa

FBBO Gold Member
FBBO Gold Member
Local time
7:51 PM
Joined
Nov 24, 2013
Messages
3,827
Reaction score
4,749
Location
Tampa, FL
Start a poll about how many guys have ended up hating a car because of the amount of work it needed to build it. The "bond" is a great fantasy. Make the money and allow someone to do some of the work for you. Picture just getting the car back ready to do minor body work and paint. Be able to tell people in two years that you "love" your car.

Edit- While the chassis shop has it you can detail everything else and be ready to assemble it when it comes back.

Last edited:

sam dupont

Well-Known Member
Local time
5:51 PM
Joined
Nov 9, 2020
Messages
1,650
Reaction score
2,481
Location
USA
Not sure how to find one, but a buddy showed me a parts catalog of body parts. It had exploded drawings with the parts named: i.e. I didn't know there was a rear cowl as well as a front.


Bighouse

Well-Known Member
Local time
7:51 PM
Joined
Mar 28, 2020
Messages
1,054
Reaction score
1,692
Location
New York
Thanks for all the good advice.
I’ve been self employed for twenty years and I’m in a position where I have lots of free time. I understand the complexity of the task. My goal is to have a hobby that will give me something to do. Being young and semi retired can be a curse if you don’t stay busy. I Have a veteran body shop for all metal installs. I just want to do all the prep work. I know my car is rough but I’ve owned finished cars that someone else built and they felt soulless to me. Cool to own, but didn’t fit my personality. I also have five kids that are very excited to have this project. We’ve had Hellcats and Humvee’s, but this one is their favorite. It’s my favorite car of all time. I’m truly grateful for your responses. If I was easily scared by big task, I would’ve never stared a successful business. After all I was a high school dropout headed for prison or death. At least that’s what the adults in my life told me.

Sounds good- I saw the ultra clean garage and thought uh-oh!!


coloradodanny

Member
Local time
5:51 PM
Joined
Oct 17, 2022
Messages
20
Reaction score
25
Location
colorado springs
Update: I ordered the two 70 manuals recommended. She’s scheduled to go to the body shop in 2/23. Earliest available. The shop owner and I have a solid plan starting with a frame jig. With the down time, I’m going to read all I can. I’m also going to start working on my 440 and 727. I really appreciate the good advice. Thanks.
