    The 69 Road Runner that I am getting ready to purchase has an aluminum radiator installed. I would like to switch it back to the factory correct style radiator. What I am unable to determine is whether it should be a 22" or 26" radiator. I have seen pictures with both setups, but I want to make sure it is right. The car is a 383 with automatic transmission (with power steering if that makes any difference). Not sure if there would be any other indicators. Would appreciate some feedback.

  2. R413

    R413 Well-Known Member

    Messages:
    2,958
    Likes Received:
    6127
    Joined:
    Feb 4, 2019
    Location:
    NW USA
    Local Time:
    5:17 PM
    Got a fender tag or Broadcast sheet? What size core support is in the car?

    a 383 without any options Like trailer tow, HD cooling or an axle package is a 22” radiator 2949053

    • Agree Agree x 3
    • Jerry Hall

      Jerry Hall FBBO Gold Member FBBO Gold Member

      Messages:
      7,726
      Likes Received:
      13180
      Joined:
      Mar 26, 2018
      Location:
      Alabama
      Local Time:
      7:17 PM
      Easy way, measure the width of the core support opening in front of the radiator. Unless it's been changed, your answer is there.

      • Agree Agree x 2
      • 3white74

        3white74 FBBO Gold Member FBBO Gold Member

        Messages:
        3,005
        Likes Received:
        462
        Joined:
        Oct 17, 2010
        Location:
        albany,ny
        Local Time:
        8:17 PM
        I have a 22 inch ....2949053 .... correct radiator if you need that one .....let me know

      • chtampa

        chtampa FBBO Gold Member FBBO Gold Member

        Messages:
        3,435
        Likes Received:
        4307
        Joined:
        Nov 24, 2013
        Location:
        Tampa, FL
        Local Time:
        8:17 PM
        Good for you. Aluminum radiators on Muscle Cars are like Spandex on a fat chick. She could be the nicest person, but wearing something cheap makes her look like a scuz bucket.

        • Like Like x 3
        • Agree Agree x 2
        • Thanks! Thanks! x 1
        • Don67Satellite

          Don67Satellite Well-Known Member

          Messages:
          390
          Likes Received:
          490
          Joined:
          Dec 16, 2021
          Location:
          Abbotsford, British Columbia, Canada
          Local Time:
          5:17 PM
          :rofl:

        • 1969VAGTX

          1969VAGTX FBBO Gold Member FBBO Gold Member

          Messages:
          203
          Likes Received:
          228
          Joined:
          Jan 11, 2022
          Location:
          Fredericksburg, VA
          Local Time:
          8:17 PM
          Thanks for the feedback. Think I have some idea now of how to determine the correct radiator. As an aside, the car does have the fender tag, but no broadcast sheet that I am aware of.

        • 69roadr

          69roadr Well-Known Member

          Messages:
          1,587
          Likes Received:
          1115
          Joined:
          Mar 1, 2012
          Location:
          Golden Valley AZ
          Local Time:
          8:17 PM
          Fender tag should State what size radiator is in it and say "end" after the number

        • Runner 68

          Runner 68 Tarnished Bronze Member FBBO Gold Member

          Messages:
          3,391
          Likes Received:
          3882
          Joined:
          Feb 22, 2013
          Location:
          The Red Anvil Dog House
          Local Time:
          6:17 PM
          That's debatable.
          It all depends on what else the so called Fat Chick is packing. Don't judge her by the color of her lipstick alone. :D
          A well made polished aluminum radiator makes and engine compartment pop.
          Black, original, painted boring assed radiators look like @ss IMHO.

        • R413

          R413 Well-Known Member

          Messages:
          2,958
          Likes Received:
          6127
          Joined:
          Feb 4, 2019
          Location:
          NW USA
          Local Time:
          5:17 PM
          Unless it was made at Lynch Road, plant A in 7th digit of the VIN.

          @1969VARdRnnr what is the 7th VIN digit. Can you show your fender tag?

          • Like Like x 1
          • chtampa

            chtampa FBBO Gold Member FBBO Gold Member

            Messages:
            3,435
            Likes Received:
            4307
            Joined:
            Nov 24, 2013
            Location:
            Tampa, FL
            Local Time:
            8:17 PM
            I prefer to embrace the equipment that the Engineers at Chrysler developed for use in the vehicles that the Mopar community apparently love. Is there any evidence that an Aluminum radiator functions any better than an OEM, or is this just a fast and cheap alternative like sidepipes and airshocks? Cudos to the car owner that makes the extra effort to remain loyal to the heritage of the brand. Personally, when I see a restored vehicle with an aluminum radiator or a parts store battery it indicates a start of other shortcuts or copying what they have seen. Aluminum radiators have a place in customized streetrods where lipstick is warranted. Again, the mixing of parts from various themes shows a lack of planning, unless that was your plan in the first place. My opinion of course and I also hate driving through a neighborhood and seeing a purple house as it violates my fragile sensibilities. I love the subtle look of boring asses, they hide surprises. <insert smiley green emoticon to not piss off anyone>

          • WileERobby

            WileERobby Well-Known Member

            Messages:
            10,894
            Likes Received:
            16509
            Joined:
            Sep 15, 2009
            Location:
            State of insanity
            Local Time:
            8:17 PM
            And here, I like "fast & cheap", lipstick, and purple houses.......

            • Thanks! Thanks! x 1
            • 69Coronetrt

              69Coronetrt Well-Known Member

              Messages:
              3,310
              Likes Received:
              2348
              Joined:
              Jul 17, 2008
              Location:
              Harlan, IA
              Local Time:
              7:17 PM
              IF the car has:

              Only A/C (H51 coded on tags from LA, Lynch Road and St. Louis) it will have a 26" 055 radiator
              Trailer Towing (A35 coded on LA and St. Louis tags but not on LR) gets the 26" 054
              Axle Package (A31 and A36 coded on LA and St. Louis tags. Show as 642, 643, 591 and 594 AXLE assembly codes on LR tag) get the 26" 054.

              You should find 26 on the fender tag if the car has any of the above.

              A standard 383 automatic with none of the above gets the 22" 053 radiator. This will not be coded on the fender tag.

              Meaning....no 26 on the tag = 22'' radiator.

              • Like Like x 1
              • Agree Agree x 1
              • RJRENTON

                RJRENTON FBBO Gold Member FBBO Gold Member

                Messages:
                2,653
                Likes Received:
                2493
                Joined:
                Jul 1, 2015
                Location:
                South Shores area of Decatur, Illinois
                Local Time:
                7:17 PM
                Absolutely nothing wrong with a slightly overweight chick wearing a little bit of "enhancement" help....as beauty is the eye of the beholder.....or.....as an old cigarette advertisement use to say: "it's roung and firm and fully packed....and sooo...satisfing"....but....one must draw or experience their own conclusions..... just my opinion of course...
                BOB RENTON

              • chtampa

                chtampa FBBO Gold Member FBBO Gold Member

                Messages:
                3,435
                Likes Received:
                4307
                Joined:
                Nov 24, 2013
                Location:
                Tampa, FL
                Local Time:
                8:17 PM
                Here you go!

                • Like Like x 2
                • RJRENTON

                  RJRENTON FBBO Gold Member FBBO Gold Member

                  Messages:
                  2,653
                  Likes Received:
                  2493
                  Joined:
                  Jul 1, 2015
                  Location:
                  South Shores area of Decatur, Illinois
                  Local Time:
                  7:17 PM
                  Perhaps, you will recall the old expression that the San Francisco '49er prospectors used: "Gold is where you find it".....OR.....defined by one's expectations, experiences.....and......underlying NEED......
                  BOB RENTON

                • chtampa

                  chtampa FBBO Gold Member FBBO Gold Member

                  Messages:
                  3,435
                  Likes Received:
                  4307
                  Joined:
                  Nov 24, 2013
                  Location:
                  Tampa, FL
                  Local Time:
                  8:17 PM
                  I'm sure there is some gold in those two girls.

                • 1969VAGTX

                  1969VAGTX FBBO Gold Member FBBO Gold Member

                  Messages:
                  203
                  Likes Received:
                  228
                  Joined:
                  Jan 11, 2022
                  Location:
                  Fredericksburg, VA
                  Local Time:
                  8:17 PM
                  Seventh digit is a "G" which I believe indicates it was built in St. Louis (at least according to the decoder I used online).

                  • Agree Agree x 2
                  • 1969VAGTX

                    1969VAGTX FBBO Gold Member FBBO Gold Member

                    Messages:
                    203
                    Likes Received:
                    228
                    Joined:
                    Jan 11, 2022
                    Location:
                    Fredericksburg, VA
                    Local Time:
                    8:17 PM
                    None of the codes you reference above are on the fender tag. The only place the number 26 appears coincides with the build date on the fender tag. So I take that to mean it came with a 22" radiator.

                    • Agree Agree x 2
                    • 1969VAGTX

                      1969VAGTX FBBO Gold Member FBBO Gold Member

                      Messages:
                      203
                      Likes Received:
                      228
                      Joined:
                      Jan 11, 2022
                      Location:
                      Fredericksburg, VA
                      Local Time:
                      8:17 PM
                      Now you guys are just hijacking the thread. I don't need to see this outside of the "restricted" forums!
