Unfortunately I dont have any pictures, But what I did for my radio in my 73 bird, was cut a hole in my glove box bucket between the heater box, and the ac ducts, it is just big enough to squeeze an aftermarket deck in. To make it look good, I picked up an under the dash mounting kit off of a local custom radio shop for 25 bucks. The original measurements were 9 by 11 I think, 11 inches, was far too deep to fit in the glove box, so I cut it practically in half, I forget the exact measurement as it wasnt directly half of it. I pre drilled four holes in the top of the glove box bucket after I had it mocked up and then screwed it in. It is sturdy, it looks completely original when the glove box is closed, and it still looks great and I get a ton of compliments when they see how I have it set up. I took two small component speakers and mounted them in my drivers and passenger door, there are two holes already on the inside of the door, just measure the depth and width and then source out the speakers. for the rears, I mounted two aftermarket jbl's in the original speaker locations. I run an amp that is located under my rear seat, with the wires running under the carpet, The whole interior looks 95 percent original, the 5 percent that doesnt look original are the speakers in the door, but they don't look bad if you do it right! if anyone would like pictures feel free to call or text me 774 364 4026
