NEW MEMBER '69 Charger R/T Power BRAKE Booster issues

Bcumbee

New Member
Local time
9:44 AM
Joined
Apr 28, 2022
Messages
3
Reaction score
5
Location
Motor City
Ok. I have a 69 charger w power front disc, rear drum setup. I purchased new calipers, upper lines, master cylinder and brake booster from inline tube. I've installed. Bled several times, including bench bleed on MS, however i had to change my calipers twice and the chamber ran empty for a min, i filled before touching the pedal (could i need another bench bleed). No leaks. The new booster was a really tight fit in firewall.

I have no pedal. I have pressure when I bleed and get good fluid with no bubbles. Engine off - after 1 press of the pedal its stiff, while holding I start Engine and pedal falls to floor. Engine running - pull check valve and have great suction and RPMs drop.

My booster makes an odd sound, like a squish or suction when Engine running and pedal reaches the bottom.
Can my linkage be wrong, could it be the tight clearance in the firewall... its killing me. I've wanted this car for 20+ years and I got it a couple months ago. I've done a ton to it and this last thing is stopping me from cruising. PLEASE help. No bad ideas.

20220428_161426.jpg 20220428_154122.jpg 20220425_133510.jpg 20220412_114716.jpg 20220428_161639.jpg 20220325_131335.jpg 20220326_041806.jpg 20220311_034753.jpg 20220310_115914.jpg

Last edited:

toolmanmike

Henchman #2
Staff member
FBBO Gold Member
Local time
8:44 AM
Joined
Aug 11, 2010
Messages
8,409
Reaction score
14,923
Location
Iowa
Welcome to FBBO. You may get better action on your brake problem by starting a thread in the brake section. Nice Charger.


pnora

FBBO Gold Member
FBBO Gold Member
Local time
9:44 AM
Joined
Apr 21, 2020
Messages
2,449
Reaction score
2,609
Location
Ishpeming, Mi.
1-Make sure the booster to master push rod is adjusted correctly.
2- Bench bleed the master and make sure you are fully bleeding both chambers.
3- Make sure the pads are seating correctly.
4-Make sure the caliper bleeders are on top.
5-Make sure the rear is adjusted correctly.
6- Start with a gravity bleed one wheel at a time. Do all 4.
7- Have an assistant and pressure bleed one wheel at a time.
All steps followed you should have brakes.


69 Sleeper Bee

Well-Known Member
Local time
9:44 AM
Joined
Feb 18, 2021
Messages
2,216
Reaction score
3,289
Location
Tallahassee Florida
Welcome from North Florida !!!
Nice looking Charger.
Did the brakes work when you bought it or is this a problem that just happened after you worked on the brakes?


Jerry Hall

FBBO Gold Member
FBBO Gold Member
Local time
8:44 AM
Joined
Mar 26, 2018
Messages
7,991
Reaction score
13,783
Location
Alabama
Welcome from Alabama, nice Charger, brakes or no brakes.


Bcumbee

New Member
Local time
9:44 AM
Joined
Apr 28, 2022
Messages
3
Reaction score
5
Location
Motor City
Welcome from North Florida !!!
Nice looking Charger.
Did the brakes work when you bought it or is this a problem that just happened after you worked on the brakes?

They functioned, not great. I drove it about 1k miles. Had a small leak on a bleeder, a union to the rear lines and back of the master. That's why I replaced everything.


lemondana

Well-Known Member
Local time
8:44 AM
Joined
Aug 18, 2008
Messages
191
Reaction score
192
Location
Lincoln NE
Is your Charger a factory power disc brake car? If so-you had the BEST booster on it that you can use. The Bendix Dual Diaphragm is a much better booster than anything available in the kits. Get your original Bendix booster rebuilt, find the right master cylinder, or get yours rebuilt and sell all of the crap that you bought! I see so many of these upgraded kits with these tiny boosters, no wonder they don't work worth a damn.


Budnicks

You Can Just Thank Me Later
FBBO Gold Member
Local time
6:44 AM
Joined
Jan 16, 2011
Messages
61,903
Reaction score
75,474
Location
NorCal Sierras
Welcome to FBBO
hopefully you get it sorted out

more detailed info, what's been done or tried/replaced
(even photos) you can give here
the easier
it is to help diagnose the problems


chickendeluxe

Well-Known Member
Local time
9:44 AM
Joined
Nov 20, 2011
Messages
147
Reaction score
56
Location
Silver Spring, MD
Same set up.
My pedal pressure improved by lengthening the Booster to MC rod about a 1/4 inch.
Use a 5/16 wrench and a 6mm socket.
Eventually I wound it all the way out.
I also adjusted the rear shoes and that helped too.
