Switching to Electronic Ignition

Electrical & Ignition

  1. VFilms

    VFilms Well-Known Member

    Messages:
    105
    Likes Received:
    61
    Joined:
    Nov 12, 2014
    Location:
    Saratoga NY
    Local Time:
    11:36 PM
    I plan to switch over to electronic ignition for my '66 Belvedere 318 POLY (now 392). I have been told that the ignition switch has to be replaced as well. Is this correct?
    Also, suggestions on which EI manufacturer or perhaps later model MOPAR.
    Thanks

  2. Bill Monk

    Bill Monk FBBO Gold Member FBBO Gold Member

    Messages:
    2,160
    Likes Received:
    2504
    Joined:
    Feb 27, 2017
    Location:
    West Virginia
    Local Time:
    11:36 PM
    FBO is quality american made products. I have it and love mine. If you give him your specs, he will curve and phase the distributor as well. Never heard of replacing the switch, don't know why you would need to do that
    Here's the web site on a conversion kit: http://4secondsflat.com/Ignition.html

    • Thanks! Thanks! x 1
    • threewood

      threewood FBBO Gold Member FBBO Gold Member

      Messages:
      4,182
      Likes Received:
      4880
      Joined:
      May 30, 2014
      Location:
      Yuma, AZ
      Local Time:
      8:36 PM
      Never heard of replacing the switch either. Have a look at Pertronix as well. Drops into the distributor and you can eliminate the ballast resistor. Look the the II or III

      • Agree Agree x 1
      • Bill Monk

        Bill Monk FBBO Gold Member FBBO Gold Member

        Messages:
        2,160
        Likes Received:
        2504
        Joined:
        Feb 27, 2017
        Location:
        West Virginia
        Local Time:
        11:36 PM
        Same with Don's conversion at FBO. Ballest resistor is bypassed

      • vintage chromoly

        vintage chromoly FBBO Gold Member FBBO Gold Member

        Messages:
        1,704
        Likes Received:
        2826
        Joined:
        Nov 13, 2010
        Location:
        ohio
        Local Time:
        10:36 PM
        No need to replace the switch

        • Agree Agree x 2
        • 493 Mike

          493 Mike FBBO Gold Member FBBO Gold Member

          Messages:
          1,814
          Likes Received:
          1860
          Joined:
          Dec 25, 2011
          Location:
          White Cloud, MI
          Local Time:
          11:36 PM
          I put GM HEI on my poly. Starts great! Reasonable priced. Interested- PM me and I'll give you the whole story.
          Mike

        • 69a100

          69a100 Well-Known Member

          Messages:
          7,122
          Likes Received:
          9553
          Joined:
          Aug 22, 2012
          Location:
          The Real World
          Local Time:
          8:36 PM
          Early Charging System modified for use with a 70 style VR

          There are a number of reasons one might want to upgrade a per-1970 system to a transistorized voltage regulator. The list of reason include

          • Chrysler recommends you switch to a transistorized VR if you upgrade to an electronic ignition from a points style ignition.
          • If you have to buy a new voltage regulator, the difference in cost is only about $5-10 more for the transistorized unit. Not to mention, the quality of replacement early style VR's is spotty.
          • The transistorized VR will have a longer life.
          • GOOD LUCK
          http://www.imperialclub.com/Repair/Electrical/charging.htm

          • Agree Agree x 1
          • Demonic

            Demonic Well-Known Member

            Messages:
            780
            Likes Received:
            647
            Joined:
            Jun 5, 2017
            Location:
            Over the hills, far away
            Local Time:
            11:36 PM
            Can't think of a reason to replace the switch. Good advise above.

            • Thanks! Thanks! x 1
            • VFilms

              VFilms Well-Known Member

              Messages:
              105
              Likes Received:
              61
              Joined:
              Nov 12, 2014
              Location:
              Saratoga NY
              Local Time:
              11:36 PM
              Thanks to all. I very much appreciate the info. I've been away from building cars for about 20 years. Was just wondering what was new in EI.
              A Chevy friend told me about the switch. Didn't make sense to me either. Should probably stop listening to my Chevy friends.

              69a100... not sure about your graphic. I'm guessing it's because my question's been asked a million times before. Funny though.

            • 69a100

              69a100 Well-Known Member

              Messages:
              7,122
              Likes Received:
              9553
              Joined:
              Aug 22, 2012
              Location:
              The Real World
              Local Time:
              8:36 PM
              I've used that more then I'd like to, there's a long dirty story behind it!

            • GetX'd

              GetX'd Making Life Great Again!

              Messages:
              9,267
              Likes Received:
              8393
              Joined:
              Jul 20, 2014
              Location:
              Laguna Beach, CA
              Local Time:
              8:36 PM
              I bought the evil empire MSD Ready to Run. No need for the additional red box. Runs great. Nothing really to maintain. Slick setup. Maybe a little pricey tho. I think it was around $500. Can’t really remember. Purchased from Summit. Worth comparing to the others.

            • Gpuller

              Gpuller Well-Known Member

              Messages:
              2,523
              Likes Received:
              1342
              Joined:
              Jun 16, 2010
              Location:
              Minnesota
              Local Time:
              10:36 PM
              BINGO!!!!

            • threewood

              threewood FBBO Gold Member FBBO Gold Member

              Messages:
              4,182
              Likes Received:
              4880
              Joined:
              May 30, 2014
              Location:
              Yuma, AZ
              Local Time:
              8:36 PM
              The 66 should have the black box on the firewall. I put a solid state one in each of my cars and have a few spares. Very inexpensive not to make the switch. This one... https://www.ebay.com/itm/Mopar-Volt...riorityMailPaddedFlatRateEnvelope!85367!US!-1

            • Demonic

              Demonic Well-Known Member

              Messages:
              780
              Likes Received:
              647
              Joined:
              Jun 5, 2017
              Location:
              Over the hills, far away
              Local Time:
              11:36 PM
              That's not my quote.

            • VFilms

              VFilms Well-Known Member

              Messages:
              105
              Likes Received:
              61
              Joined:
              Nov 12, 2014
              Location:
              Saratoga NY
              Local Time:
              11:36 PM
              :thumbsup:

            • 69a100

              69a100 Well-Known Member

              Messages:
              7,122
              Likes Received:
              9553
              Joined:
              Aug 22, 2012
              Location:
              The Real World
              Local Time:
              8:36 PM
              Where's my meme, "Here we fuckin go again"? Screw your black box, fuck that thing!!! Use what's said in the link!!!! Why are people so obtuse about this and say otherwise? When it leaves you hangin on the side of the road all borked up, don't come cryin to me!!!
              I never said it was. What am I missing?

              Last edited: Jan 14, 2020
            • Demonic

              Demonic Well-Known Member

              Messages:
              780
              Likes Received:
              647
              Joined:
              Jun 5, 2017
              Location:
              Over the hills, far away
              Local Time:
              11:36 PM
              I think it's a glitch. Post #10 starts with "Demonic said". The quote is actually from post #9. At least that's how it appears here.

            • Nacho-RT74

              Nacho-RT74 Well-Known Member

              Messages:
              3,236
              Likes Received:
              1020
              Joined:
              Oct 8, 2012
              Location:
              Caracas, Venezuela
              Local Time:
              11:36 PM
              I simply would go with Pertronix ignitor I or II and call it done! No hard mods needed. Replace the points inside the dist with the Pertronix module, jumper wire on ballast ( or modify ballast to remove the resistor in back and replace with a wire ) and you’ll be ready to go. Everything will look stock and will be easy to get it back if wished for some reason

              Last edited: Jan 16, 2020
