Looking to replace my radiator

Heating, Cooling & AC

  1. Napoleon1991

    Napoleon1991 Well-Known Member

    Messages:
    130
    Likes Received:
    72
    Joined:
    Sep 4, 2016
    Location:
    illinois
    Local Time:
    7:37 PM
    I need some help with my cooling system. Im looking for a 22" radiator that will cool the 440 in my 65 coronet. I currently have a 7 blade flex fan and a 3 row summit aluminum rad that just isnt cutting it at idle or slow speeds. Im looking to switch to a stock style clutch fan and shroud and a better radiator. Ive done alot of searching, but most of the radiator suppliers list their products as fitting 66 and up cars. Is there a reason that some of these radiators wont fit a 65? Some of the brands im looking at are OER, Griffin & Wizard.

  2. turbine68rt

    turbine68rt Turbine Bronze Member FBBO Gold Member

    Messages:
    1,293
    Likes Received:
    1780
    Joined:
    Dec 1, 2019
    Location:
    PA
    Local Time:
    8:37 PM
  3. VANDAN

    VANDAN FBBO Gold Member FBBO Gold Member

    Messages:
    1,862
    Likes Received:
    3254
    Joined:
    May 27, 2011
    Location:
    Western NY
    Local Time:
    8:37 PM
    1226191356.jpg Call Bob Schirmer, at Glen-ray Radiators. Never Worry Again. They will give you a Correct look unit, that will out-perform any other...

    • Agree Agree x 5
    • Napoleon1991

      Napoleon1991 Well-Known Member

      Messages:
      130
      Likes Received:
      72
      Joined:
      Sep 4, 2016
      Location:
      illinois
      Local Time:
      7:37 PM
      Are they really worth the price? Seems very expensive. Im not going for a factory correct look, just need something that will cool.

    • Napoleon1991

      Napoleon1991 Well-Known Member

      Messages:
      130
      Likes Received:
      72
      Joined:
      Sep 4, 2016
      Location:
      illinois
      Local Time:
      7:37 PM
    • 6-david-5

      6-david-5 Well-Known Member

      Messages:
      106
      Likes Received:
      54
      Joined:
      Sep 20, 2015
      Location:
      L A area
      Local Time:
      5:37 PM
      Does your next radiator "have" to be a 22"?
      What size is your Summit radiator?
      What pump are you using?
      Stock (crank) pulleys?
      I believe the '66-up listings are due to whether the flanges will line up with your core support and bolt up.
      I will never forget the time (years ago) I saw a '64 Belvedere at the track with a 440, and when I talked to the owner, he said he ran a Ford radiator. It looked like a 26-ish-sized unit and probably from a full-sized Ford car. He probably had to drill his core support & make that happen. He spoke of it like he solved temp issues, but I digress...
      In my '65 Belvedere (avatar), I found a universal replacement Northern radiator, and set up dual SPAL electric fans. It would still get elevated temps in a CA summer traffic jam (215*), but nothing that made me pull over. Cruising temps were around 180-195*.

      Are you trying to make it look original? Is this a priority?

      I have a feeling you may be able to do something with the radiator you have. Show us some photos of the underhood of your Coronet!

    • hugh68charger

      hugh68charger Well-Known Member

      Messages:
      55
      Likes Received:
      114
      Joined:
      Feb 25, 2020
      Location:
      south florida
      Local Time:
      8:37 PM
      I just got a 26 inch Glenn-ray radiator for my 440 Charger and I could not be any happier. I put in a Milodon high volume water pump and a 180 degree thermostat and instead of cringing when I look at my temp gauge I look forward to watching what it is reading. I am in south Florida and it can get hot here and traffic can be brutal. The truth is I would have paid more just to enjoy the peace of mind I have now.

      Last edited: Apr 10, 2021
      • Agree Agree x 1
      • Napoleon1991

        Napoleon1991 Well-Known Member

        Messages:
        130
        Likes Received:
        72
        Joined:
        Sep 4, 2016
        Location:
        illinois
        Local Time:
        7:37 PM
        I dont care if it looks original or not. It needs to be a 22" because it cant see how a 26" would fit between the horns and the battery tray.

      • 6-david-5

        6-david-5 Well-Known Member

        Messages:
        106
        Likes Received:
        54
        Joined:
        Sep 20, 2015
        Location:
        L A area
        Local Time:
        5:37 PM
        You have valid points here.....

        On my Belvedere, I did have to cut a notch out of my battery tray to clear the left side tank of that Northern Radiator. And I did have to relocate the horns.

        This is from A Bodies and just thought I would share it:
        https://www.forabodiesonly.com/mopar/threads/cordoba-radiator-in-72-duster.438916/

        And I wanted to share this because I did something very similar to my 383 '68 Dart, but I used a late '80's B250 van radiator with dual electric fans from a modern Charger/Challenger. I spent the time on this one by notching the battery tray, moving the horns and cutting/modifying the mounting brackets to the radiator. Also drilled new holes in the core support, and set-up the electric fans to fit this radiator. I realize this is all probably going in a direction you may not care to pursue, but I'll post pictures if you want to know more. It DID work, and the car runs at normal temperatures in LA traffic in August!

        David

      • dan juhasz

        dan juhasz FBBO Gold Member FBBO Gold Member

        Messages:
        1,008
        Likes Received:
        1028
        Joined:
        Aug 5, 2016
        Location:
        Manalapan, NJ
        Local Time:
        8:37 PM
        Sounds like your radiator is good if it maintains temp of 185 while your moving, if your not concerned about stock appearance add a shrouded electric fan for slow moving traffic situations

        • Agree Agree x 1
        • Ron H

          Ron H FBBO Gold Member FBBO Gold Member

          Messages:
          4,553
          Likes Received:
          4807
          Joined:
          Feb 29, 2016
          Location:
          WI
          Local Time:
          7:37 PM
          When I had overheating issues on my ’63 Ply, after some motor performance upgrades, I installed a 7 blade fan and OEM shroud. Researching shrouds, found that some of the after-market, just might create more of an issue with cooling – air flow. As such, I decided to locate an OEM for my car. Got a tip to install a top seal over the radiator (it was optional on my car so put this on). I was close to buying a new rad; but doing more reading and some tips, learned that the ratio of anti-freeze to water influences engine temp. A 50/50 mix, normal of course. I reduced the mix to around 25-30% and added a product called ‘water-wetter’. Also more sifting, found that the viscosity of oil impacts engine temp. I was running 20/50 racing oil and my oil pressure was always way high. I changed it out to 10/30 hi-zinc (have solid lifters). All this done I got real nice operating temps all the way around. While I live in WI, the lower anti-freeze ratio didn’t matter since my ride sits in a heated garage and never sees daylight in the cold. As for the oil, an interesting read as some oil guru’s say high-visc racing oil isn’t suggested for street driving – it’s for ‘racing’. There can be exceptions; but the heavier oil retains heat more than does lower visc. Anyway, my oil pressure came down where it should be, and significantly reduced motor temp…so nixed getting a new rad.

          • Like Like x 1
          • Thanks! Thanks! x 1
          • Napoleon1991

            Napoleon1991 Well-Known Member

            Messages:
            130
            Likes Received:
            72
            Joined:
            Sep 4, 2016
            Location:
            illinois
            Local Time:
            7:37 PM
            I have tried different fans both mechanical and electric, shrouded and unshrouded but still have issues sitting in traffic. I would prefer to use a mechanical fan as im not crazy about how noisy the electric ones are.

          • davek

            davek Well-Known Member

            Messages:
            4,842
            Likes Received:
            4286
            Joined:
            Oct 14, 2017
            Location:
            columbia SC
            Local Time:
            8:37 PM
            You will have to take a 2nd mortgage on your house to buy one :lol:

          • Napoleon1991

            Napoleon1991 Well-Known Member

            Messages:
            130
            Likes Received:
            72
            Joined:
            Sep 4, 2016
            Location:
            illinois
            Local Time:
            7:37 PM
            Thanks for the link. Sounds like its effective. I may have to go that route if nothing else works. I would prefer to use a 22" rad for simplicity but im second guessing the quality of my summit aluminum rad.

          • Napoleon1991

            Napoleon1991 Well-Known Member

            Messages:
            130
            Likes Received:
            72
            Joined:
            Sep 4, 2016
            Location:
            illinois
            Local Time:
            7:37 PM
            Haha I noticed that! Had to look twice to make sure i read it right when i saw the prices.

          • davek

            davek Well-Known Member

            Messages:
            4,842
            Likes Received:
            4286
            Joined:
            Oct 14, 2017
            Location:
            columbia SC
            Local Time:
            8:37 PM
            do you have a shroud?

          • Napoleon1991

            Napoleon1991 Well-Known Member

            Messages:
            130
            Likes Received:
            72
            Joined:
            Sep 4, 2016
            Location:
            illinois
            Local Time:
            7:37 PM
            I had tried a shroud but it didnt make much of a difference

          • davek

            davek Well-Known Member

            Messages:
            4,842
            Likes Received:
            4286
            Joined:
            Oct 14, 2017
            Location:
            columbia SC
            Local Time:
            8:37 PM
            your fan needs to be a 1/3 out of the shroud for it to work properly.

            • Agree Agree x 1
            • 1967coronet

              1967coronet FBBO Gold Member FBBO Gold Member

              Messages:
              2,969
              Likes Received:
              3654
              Joined:
              Jun 19, 2014
              Location:
              Iowa
              Local Time:
              7:37 PM
              With that 3 core radiator if your running 180 - 190 on the road when its hot out I think a fan swap to a oem style clutch or 7 blade fixed plus adding a shroud should cool it down at slow speed and idle. Make sure your hood to rad support seal is good and back of hood to cowl seal also.
              make sure you have a good 180 thermostat.
              Also do not waste your $ on one of those chrome universal shrouds use a oem style do some measuring and hit the web sights or swap meets.

              • Agree Agree x 1
              • 65-440

                65-440 Well-Known Member

                Messages:
                3,130
                Likes Received:
                2616
                Joined:
                Dec 2, 2009
                Location:
                virginia beach, va
                Local Time:
                10:37 PM
                For what it's worth I don't think a new radiator will solve your issues. Definitely sounds like a lack of airflow once the vehicle stops moving. On my big block I'm running a factory 7 blade fan, heavy duty fan clutch from napa for a 1970 hemi coronet, factory style shroud. Fan blades are half in/half out of the shroud. It pulls plenty of air across the radiator and has zero cooling issues at idle. Typically a "lack of radiator" will show up at cruising speed when you know airflow is not the issue....unless your water pump isn't doing its job! ....which could also give you issues at idle too
                ..

                • Agree Agree x 4
