Newbie to the group with a question about distributor pickups

Welcome Wagon

  1. Don A. Gross

    Don A. Gross New Member

    Messages:
    3
    Likes Received:
    2
    Joined:
    May 14, 2022
    Location:
    West Virginia
    Local Time:
    3:10 PM
    Recently purchased a 1975 Cordoba with 47K miles in good shape somewhat. Test drove it a few times with hesitancy on acceleration thinking its a gummed up carburetor. Parked it and next day it will not start. I'm trying to learn about the ignition electronics. No spark from the secondary -coil wire. Put a new ballast resistor, new electronic module, and new voltage regulator on it. Bought a new electronic coil pickup to replace. Before I do that I want to know how to test the pickup without taking the distributor out of the car. Do I do an Ohms test on the 2 wires connected to the distributor and have someone crank the motor to see if there is a change with resistance; and if so, how many Ohms would tell me its good or bad. I read doing a coil test with resistance of 8000 Ohms on the primary and I think it was 18,000 Ohms on the secondary. Could the coil still be bad, and how do I test the primary regarding voltage. Again, I'm new to this electronic testing. Thanks. Don.

    • Like Like x 1
    • Don Frelier

      Don Frelier FBBO Gold Member FBBO Gold Member

      Messages:
      5,569
      Likes Received:
      7116
      Joined:
      Oct 11, 2016
      Location:
      Ionia, NY
      Local Time:
      3:10 PM
      • Agree Agree x 1
      • 1 Wild R/T

        1 Wild R/T FBBO Gold Member FBBO Gold Member

        Messages:
        6,039
        Likes Received:
        14583
        Joined:
        Jul 9, 2019
        Location:
        California
        Local Time:
        12:10 PM
        Often the air gap is to wide... I believe the spec is .008-.012... Best to stay toward the .008 or even .006

        • Agree Agree x 2
        • Don Frelier

          Don Frelier FBBO Gold Member FBBO Gold Member

          Messages:
          5,569
          Likes Received:
          7116
          Joined:
          Oct 11, 2016
          Location:
          Ionia, NY
          Local Time:
          3:10 PM
          3 thickness of standard paper is a good gauge

          • Agree Agree x 2
          • DodgeBoy5150

            DodgeBoy5150 FBBO Gold Member FBBO Gold Member

            Messages:
            122
            Likes Received:
            174
            Joined:
            May 2, 2021
            Location:
            The Lowcountry, Palmetto State
            Local Time:
            3:10 PM
            :welcome: from South Carolina!
            Let's see some pics of your 'Doba!

            • Agree Agree x 1
            • Jerry Hall

              Jerry Hall FBBO Gold Member FBBO Gold Member

              Messages:
              7,743
              Likes Received:
              13200
              Joined:
              Mar 26, 2018
              Location:
              Alabama
              Local Time:
              2:10 PM
              Welcome from Alabama, we need pictures running or not. Your problem reminds me why I keep the points. I know yours didn't come with points, but with Don's post you should be on your way.

              • Agree Agree x 1
              • bm02tj

                bm02tj Well-Known Member

                Messages:
                2,591
                Likes Received:
                5553
                Joined:
                Jan 27, 2013
                Location:
                BC Canada
                Local Time:
                12:10 PM
                Use non metallic feeler gauge

                • Agree Agree x 1
                • Don67Satellite

                  Don67Satellite Well-Known Member

                  Messages:
                  395
                  Likes Received:
                  491
                  Joined:
                  Dec 16, 2021
                  Location:
                  Abbotsford, British Columbia, Canada
                  Local Time:
                  12:10 PM
                  :welcome:

                • mopar 3 B

                  mopar 3 B Well-Known Member

                  Messages:
                  10,768
                  Likes Received:
                  8065
                  Joined:
                  Aug 25, 2014
                  Location:
                  Kingsville, MO
                  Local Time:
                  2:10 PM
                  And check more than one lobe

                  • Agree Agree x 1
                  • multimopes

                    multimopes FBBO Gold Member FBBO Gold Member

                    Messages:
                    2,651
                    Likes Received:
                    3597
                    Joined:
                    May 6, 2015
                    Location:
                    Columbia ,NJ
                    Local Time:
                    3:10 PM
                    Welcome aboard from NJ. As mentioned..........................

                    • Agree Agree x 1
                    • Hey-O

                      Hey-O FBBO Gold Member FBBO Gold Member

                      Messages:
                      13,198
                      Likes Received:
                      37413
                      Joined:
                      Nov 21, 2018
                      Location:
                      St. Charles, MO
                      Local Time:
                      2:10 PM
                      Welcome from Missouri!!

                    • 66Satellite47

                      66Satellite47 FBBO Gold Member FBBO Gold Member

                      Messages:
                      6,179
                      Likes Received:
                      5311
                      Joined:
                      Jan 15, 2015
                      Location:
                      St Paul MN
                      Local Time:
                      1:10 PM
                      The standard was a .007 brass gauge.

                    • HALIFAXHOPS

                      HALIFAXHOPS MSGT(ret) and MOPAR only distributor rebuilder! FBBO Gold Member

                      Messages:
                      4,364
                      Likes Received:
                      2102
                      Joined:
                      May 5, 2016
                      Location:
                      Halifax, PA USA
                      Local Time:
                      3:10 PM
                      Yes it will tell you if the upper shaft is bent. The specs are .008-.010 with a non magnetic feeler gauge. if say one lobe is .003 and one opposite is say .015 it is bent. Kind of common. The ohms were spot on mentioned above and it will not change cranking. It basically works like a small AC alt and the ecu takes the "peak" of the signal and amplifies it to send the current to the coil. Hope that helps.
                      Basic coil check. But check your FSM for actual ranges. With the wires off of the coil.

                      Last edited: May 15, 2022
                      • Like Like x 2
                      • Thanks! Thanks! x 2
                      • HALIFAXHOPS

                        HALIFAXHOPS MSGT(ret) and MOPAR only distributor rebuilder! FBBO Gold Member

                        Messages:
                        4,364
                        Likes Received:
                        2102
                        Joined:
                        May 5, 2016
                        Location:
                        Halifax, PA USA
                        Local Time:
                        3:10 PM

                        • Like Like x 2
                        • Thanks! Thanks! x 2
                        • Budnicks

                          Budnicks You Can Just Thank Me Later FBBO Gold Member

                          Messages:
                          60,385
                          Likes Received:
                          72348
                          Joined:
                          Jan 16, 2011
                          Location:
                          NorCal Sierras
                          Local Time:
                          12:10 PM
                          Welcome to FBBO from NorCal Sierras

                        • 68sprtsat383

                          68sprtsat383 FBBO Gold Member FBBO Gold Member

                          Messages:
                          4,354
                          Likes Received:
                          1812
                          Joined:
                          Dec 29, 2015
                          Location:
                          VA
                          Local Time:
                          3:10 PM
                          Welcome

                        • mr. b

                          mr. b Well-Known Member

                          Messages:
                          5,318
                          Likes Received:
                          2053
                          Joined:
                          May 5, 2011
                          Location:
                          jeannette pa
                          Local Time:
                          3:10 PM
                          welcome to FBBO from Pa

                        • polywideblock

                          polywideblock FBBO Gold Member FBBO Gold Member

                          Messages:
                          33,481
                          Likes Received:
                          85690
                          Joined:
                          Jul 31, 2014
                          Location:
                          Newcastle AU
                          Local Time:
                          5:10 AM
                          G, day from Australia:welcome:

                        • Don A. Gross

                          Don A. Gross New Member

                          Messages:
                          3
                          Likes Received:
                          2
                          Joined:
                          May 14, 2022
                          Location:
                          West Virginia
                          Local Time:
                          3:10 PM
                          Thank all of you for the reply's, especially Don Freiler. This diagram you sent me is great. After putting a new ballast, control module, coil and pickup coil, It ended being a new distributor that did it. I even took the distributor cap and rotor off the new distributor and tried it on the old one, and still nothing.
