Quincy Model 219-39 Air Compressor

kiwigtx

Henchman #4 and Jack-Stand Racer #2
Staff member
FBBO Gold Member
Local time
6:34 AM
Joined
Jun 12, 2012
Messages
29,763
Reaction score
71,478
Location
NZ - just short of the South Pole
That damn low-hanging fruit!! :lol:
Low hanging fruit you say .....

In the plums.gif


:lol:


MarPar

Cheeky Bastard
FBBO Gold Member
Local time
1:34 PM
Joined
Nov 21, 2008
Messages
16,924
Reaction score
35,344
Location
In GTXtacy Illinois
@kiwigtx

Rog, what is the best practice to move the motor aft so as to tighten the belt? It is working fine, but the belt is flopping up and down quite a bit {queue @eldubb440 lol}


kiwigtx

Henchman #4 and Jack-Stand Racer #2
Staff member
FBBO Gold Member
Local time
6:34 AM
Joined
Jun 12, 2012
Messages
29,763
Reaction score
71,478
Location
NZ - just short of the South Pole
@kiwigtx

Rog, what is the best practice to move the motor aft so as to tighten the belt? It is working fine, but the belt is flopping up and down quite a bit {queue @eldubb440 lol}
Hopefully the motor mounting holes are slotted, and hopefully there is a little bit of wiggle room left.

Slacken the 4 x bolts off a touch, and use some blocks of wood to create a 'wedge' between the motor and compressor - in order to push them apart with a lever - crowbar, pry-bar, garden spade etc....lol Basically if the compressor doesn't have jacking screws, then you just have to improvise with what you have.

The belt needs about 1/2 inch deflection measured at the centre of the two pullies - just like a car fan belt.

Tighten the bolts up, and check for squealing, slipping.....you should be fine. It will usually only slip under severe loading.

.....and for the flopping up & down......try taking two "Mycoxaphlopins' before dinner. Take with plenty of water, or else you'll end up with a stiff neck. :lol:


MarPar

Cheeky Bastard
FBBO Gold Member
Local time
1:34 PM
Joined
Nov 21, 2008
Messages
16,924
Reaction score
35,344
Location
In GTXtacy Illinois
Hopefully the motor mounting holes are slotted, and hopefully there is a little bit of wiggle room left.

Slacken the 4 x bolts off a touch, and use some blocks of wood to create a 'wedge' between the motor and compressor - in order to push them apart with a lever - crowbar, pry-bar, garden spade etc....lol Basically if the compressor doesn't have jacking screws, then you just have to improvise with what you have.

The belt needs about 1/2 inch deflection measured at the centre of the two pullies - just like a car fan belt.

Tighten the bolts up, and check for squealing, slipping.....you should be fine. It will usually only slip under severe loading.

.....and for the flopping up & down......try taking two "Mycoxaphlopins' before dinner. Take with plenty of water, or else you'll end up with a stiff neck. :lol:

:rofl::rofl: :rofl:

Will do Rog, :thankyou:
