Leaking 727B transmission

dadsbee

FBBO Gold Member
FBBO Gold Member
Local time
8:06 AM
Joined
Jan 29, 2018
Messages
14,977
Reaction score
42,425
Location
Midland Ontario, Canada
Yep.. why we cheat.. clean and seal!!! Or you can cut the retainer "tab" off the tail housing with a cut wheel in a dremel and then make a little metal bracket to bolt back on and retain the pin.


dvw

FBBO Gold Member
FBBO Gold Member
Local time
8:06 AM
Joined
Feb 16, 2010
Messages
7,004
Reaction score
11,222
Location
waterford mi
Cutting the retainer off will get you nowhere. You'll never get the pin out. And if you somehow were able to remove the pin, all the reverse band linkage would fall in the pan. You need to pull the tail shaft, valve body and rear band linkage and to remove the pin. Just seal it as I mentioned. It's not worth the hassle to swap the O ring. It can be done neatly if you work at it.
Doug


dvw

FBBO Gold Member
FBBO Gold Member
Local time
8:06 AM
Joined
Feb 16, 2010
Messages
7,004
Reaction score
11,222
Location
waterford mi
To get the rear band shaft out the valve body has to be removed. Then the rear band adjuster is loosened. Remove the band strut. Knock the band anchor pin out from the front through the access hole in the case. Take a picture first so you can see how it goes back together. Along with this, the tail shaft still needs to be removed as well.
Doug


1963JAM

Well-Known Member
Local time
8:06 AM
Joined
Sep 5, 2021
Messages
264
Reaction score
139
Location
Worcester County Massachusetts
To get the rear band shaft out the valve body has to be removed. Then the rear band adjuster is loosened. Remove the band strut. Knock the band anchor pin out from the front through the access hole in the case. Take a picture first so you can see how it goes back together. Along with this, the tail shaft still needs to be removed as well.
Doug
Thank you for the help, but tranny is staying in the car. I’ll clean up the exterior pin area outside case and glop on the RTV to plug it up.
Thank you Doug.
John


Dave6T4

Well-Known Member
Local time
8:06 AM
Joined
Dec 31, 2020
Messages
3,919
Reaction score
7,508
Location
Ontario, Canada
The transmission does not have to come out of the car to do as Doug suggested, but the drive shaft has to come out and the tail shaft housing has to come off. As well as oil pan and valve body. It would be nice to have a hoist to do this work on.


1963JAM

Well-Known Member
Local time
8:06 AM
Joined
Sep 5, 2021
Messages
264
Reaction score
139
Location
Worcester County Massachusetts
The transmission does not have to come out of the car to do as Doug suggested, but the drive shaft has to come out and the tail shaft housing has to come off. As well as oil pan and valve body. It would be nice to have a hoist to do this work on.
No hoist. On my back with car on ramps.
