    Joe, I was pulling what hair I have left out over my brake issue. The vender I bought the front brake conversion was of no help. I knew the brakes were not right but I could not figure it out.

  2. Billccm

    Billccm FBBO Gold Member FBBO Gold Member

    Messages:
    1,852
    Likes Received:
    1249
    Joined:
    Aug 3, 2016
    Location:
    Tucson
    Local Time:
    9:19 PM
    I'm glad I went with Dr Diff. I've read too many brake nightmares on this forum.

    • Agree Agree x 1
    • dadsbee

      dadsbee FBBO Gold Member FBBO Gold Member

      Messages:
      2,284
      Likes Received:
      3957
      Joined:
      Jan 29, 2018
      Location:
      Ontario, Canada
      Local Time:
      12:19 AM
      I'm glad I stuck with the perfectly good OE system that hasn't failed me in the 40 years that I've been driving the car. The 16 years before that, my father forgot to hit the brake pedal in time during the first year and it got relegated (damaged) to the garage for the next 15.. LOL

    • Joe66satellite

      Joe66satellite Well-Known Member

      Messages:
      80
      Likes Received:
      22
      Joined:
      Nov 30, 2018
      Location:
      Las vegas
      Local Time:
      9:19 PM
      Thank you you're so right that is my issue right now I have a 66 satellite with a big cam 440 in it and he put a ssbc disc brake kit in it and use the original power booster and I have a tough time breaking I'd like to know if I could use that 15/16 master cylinder on the existing power booster provided I had enough vacuum

    • steve from staten island

      steve from staten island FBBO Gold Member FBBO Gold Member

      Messages:
      5,352
      Likes Received:
      6114
      Joined:
      Sep 24, 2012
      Location:
      staten island,ny
      Local Time:
      12:19 AM
      Talk to Cass at Dr Diff would be your best bet.

      • Agree Agree x 1
      • Sixpactogo

        Sixpactogo Well-Known Member

        Messages:
        979
        Likes Received:
        745
        Joined:
        Feb 2, 2014
        Location:
        Eau Claire, WI
        Local Time:
        11:19 PM
        I agree totally. First thing Cass will tell you is the original drum brake single ballast booster will not provide enough boost for disc brakes. You need the dual ballast booster.

      • b569Charger

        b569Charger Well-Known Member

        Messages:
        49
        Likes Received:
        27
        Joined:
        Dec 11, 2018
        Location:
        Michigan
        Local Time:
        12:19 AM
        I, too bought a disc brake manual to power conversion kit (by MBM), but I hear some say if you have a big cam, you won't have the vacuum to operate it. I think my cam specs are listed below...I don't know if this is considered a "big" cam or not (???)

        CLAY SMITH ENGINEERING CAMSHAFT: Model MB*H-300-8-BHL

        Valve timing (based on B rockers)
        “IN” opens 42, closes 78.
        Duration at .50 = 244 degrees
        In valve lift = .485. In valve adjust, .000

        “EX” opens 78, closes 42
        EX valve lift .485, EX valve adjust .000

        This is all greek/ mumbo jumbo to me. The car is 440 (4 speed), has headers, and I am planning to install a Mopar: P5153525 intake manifold (this is to replace a M1 hi rise on it now, Mopar intake P4532174 single plane).

        Do I have too much cam for a power brake booster?

      • b569Charger

        b569Charger Well-Known Member

        Messages:
        49
        Likes Received:
        27
        Joined:
        Dec 11, 2018
        Location:
        Michigan
        Local Time:
        12:19 AM
        Here is the cam card...I assume it's still in her

        IMG950418 (2).jpg

      • Joe66satellite

        Joe66satellite Well-Known Member

        Messages:
        80
        Likes Received:
        22
        Joined:
        Nov 30, 2018
        Location:
        Las vegas
        Local Time:
        9:19 PM
        I wish I could provide an adequate answer for that hopefully someone can cuz I'm listening too

      • b569Charger

        b569Charger Well-Known Member

        Messages:
        49
        Likes Received:
        27
        Joined:
        Dec 11, 2018
        Location:
        Michigan
        Local Time:
        12:19 AM
        I used the chat window at Summit racing and they suggested a reasonably priced vacuum booster. Was maybe $235 or so. It is a unit that is electric and creates vacuum

      • Joe66satellite

        Joe66satellite Well-Known Member

        Messages:
        80
        Likes Received:
        22
        Joined:
        Nov 30, 2018
        Location:
        Las vegas
        Local Time:
        9:19 PM
        Yeah I looked at a car that a guy did that with and he even had drum still on front, but I also had a text conversation with a guy from Summit who said that ssbc disc brake conversion kit for B body Mopar will work with the front drum power booster from the factory but they also give you a proportioning valve that you're supposed to use and follow their directions my po left out the proportioning valve
