Which ignition coil can handle constant 12V: UPDATE - car running

Electrical & Ignition

  1. Canadian1968

    Canadian1968 Well-Known Member

    Messages:
    120
    Likes Received:
    81
    Joined:
    Nov 13, 2012
    Location:
    london
    Local Time:
    10:52 AM
    I am playing around with the idea of the HEI ignition module swap inside one of our original orange boxes. Done a lot of reading it seems pretty straight forward. The biggest thing i have read, in order to take full advantage of this swap you need a coil that can handle a constant 12v. Unlike most coils that require the ballast resistor on our fire wall to drop working voltage to 8-9v range.

    I know most of the articles say to use an E-coil, but I am trying to keep it looking stock with a canister style coil. Wondering if anyone has found a coil that can handle the extra juice.??

  2. HALIFAXHOPS

    HALIFAXHOPS MSGT(ret) and MOPAR only distributor rebuilder! FBBO Gold Member

    Messages:
    3,560
    Likes Received:
    1574
    Joined:
    May 5, 2016
    Location:
    Halifax, PA USA
    Local Time:
    11:52 AM
    Look for one that has internall resistance of 1.5 ohms, petronix make one.

    • Like Like x 1
    • threewood

      threewood FBBO Gold Member FBBO Gold Member

      Messages:
      4,956
      Likes Received:
      6422
      Joined:
      May 30, 2014
      Location:
      Yuma, AZ
      Local Time:
      8:52 AM
      Pertronix Flame-Thrower coil.

      • Agree Agree x 1
      • AR67GTX

        AR67GTX Well-Known Member

        Messages:
        1,650
        Likes Received:
        830
        Joined:
        Jan 28, 2012
        Location:
        Arkansas
        Local Time:
        10:52 AM
        I thought the ballast resister was to protect the points from burning, not so much the coil? But in any event, a coil from any electronic ignition company whose instructions call for taking the ballast resister out of the system - Pertronix or MSD would be a couple.

      • Canadian1968

        Canadian1968 Well-Known Member

        Messages:
        120
        Likes Received:
        81
        Joined:
        Nov 13, 2012
        Location:
        london
        Local Time:
        10:52 AM
        It turns out an accel (super stock) coil I have has 1.4 ohm. Perfect !

        • Like Like x 1
        • Canadian1968

          Canadian1968 Well-Known Member

          Messages:
          120
          Likes Received:
          81
          Joined:
          Nov 13, 2012
          Location:
          london
          Local Time:
          10:52 AM
          Well after a bunch of reading both from different sites including MSD site itself, The coil on the car right now is a MSD street fire . Directly from MSD instructions it's says " if using points ignition a Ballast resistor MAYBE required " I stress that maybe point .

          Anyway I did the hide away HEI 4 prong swap and the car fired right up. I hate to admit but the car idea smoother and the throttle response seems a bit more crisp .

          BUT one thing I noticed . I took some readings before I unhooked anything . The regular mopat orange box and coil gave me a reading of 9.5v at idlel and a 4.5amp draw.

          With the HEI module I am getting full battery - 13.4v but only 2.2 amps I thought that was interesting .

          I wonder if u put in a matching E-coil if it would change that .

          The car also leaned out quite a bit on my wide band..... very interesting . Waiting for rain to stop will take it for a drive next
