Can 66 Sat top of fender trim split be aluminum welded?

Exterior Body, Paint, Trim, Chrome

  1. AR67GTX

    AR67GTX Well-Known Member

    Messages:
    1,572
    Likes Received:
    764
    Joined:
    Jan 28, 2012
    Location:
    Arkansas
    Local Time:
    1:49 PM
    On the search for a right front fender top piece of trim for my 66 Satellite which will apparently take awhile.

    The trim appears to have been bumped up by the turn signal bezel that apparently cracked and split it along the top about an inch and half to two inches. It was all squeezed together (no gap or crimp in the aluminum) and isn't readily apparent except for one side has an outward dent apparently from the front retaining clip when it was bumped off to the side.

    Question - can a trim restoration shop successfully weld this light weight aluminum trim successfully? If so that may be a lot easier than finding another good one.

  2. Don Frelier

    Don Frelier FBBO Gold Member FBBO Gold Member

    Messages:
    3,735
    Likes Received:
    4186
    Joined:
    Oct 11, 2016
    Location:
    Ionia, NY
    Local Time:
    2:49 PM
    Old aluminum is very difficult to weld even with a TIG welder.
    I would guess no.

  3. Nevada dan

    Nevada dan Well-Known Member

    Messages:
    245
    Likes Received:
    270
    Joined:
    Dec 28, 2020
    Location:
    Nevada
    Local Time:
    11:49 AM
    It’s probably not aluminum it’s what they called pot metal
    It can’t be welded
    Might be able to braze it but you can’t let it get too hot
    Maybe some solder or lead if you can find someone with some experience with that

  4. Don Frelier

    Don Frelier FBBO Gold Member FBBO Gold Member

    Messages:
    3,735
    Likes Received:
    4186
    Joined:
    Oct 11, 2016
    Location:
    Ionia, NY
    Local Time:
    2:49 PM
    It is aluminum I have one.

    • Agree Agree x 2
    • Jerry Hall

      Jerry Hall FBBO Gold Member FBBO Gold Member

      Messages:
      5,044
      Likes Received:
      8188
      Joined:
      Mar 26, 2018
      Location:
      Alabama
      Local Time:
      1:49 PM
      It's aluminum for the trim. The fender turn signals are chromed pot metal.

      • Agree Agree x 2
      • Nevada dan

        Nevada dan Well-Known Member

        Messages:
        245
        Likes Received:
        270
        Joined:
        Dec 28, 2020
        Location:
        Nevada
        Local Time:
        11:49 AM
        I can’t tell the difference but you will find out when you try to rig it

      • Nevada dan

        Nevada dan Well-Known Member

        Messages:
        245
        Likes Received:
        270
        Joined:
        Dec 28, 2020
        Location:
        Nevada
        Local Time:
        11:49 AM
        Tig not rig
        Damn spell check

        • Like Like x 1
        • Jerry Hall

          Jerry Hall FBBO Gold Member FBBO Gold Member

          Messages:
          5,044
          Likes Received:
          8188
          Joined:
          Mar 26, 2018
          Location:
          Alabama
          Local Time:
          1:49 PM
          I think it's to thin to rig or tig.

          • Like Like x 1
          • Agree Agree x 1
          • Nevada dan

            Nevada dan Well-Known Member

            Messages:
            245
            Likes Received:
            270
            Joined:
            Dec 28, 2020
            Location:
            Nevada
            Local Time:
            11:49 AM
            ok the taillight extensions on my runner are pretty thick i'm not familiar with those

          • Jerry Hall

            Jerry Hall FBBO Gold Member FBBO Gold Member

            Messages:
            5,044
            Likes Received:
            8188
            Joined:
            Mar 26, 2018
            Location:
            Alabama
            Local Time:
            1:49 PM
            Top of fender trim.

          • Nevada dan

            Nevada dan Well-Known Member

            Messages:
            245
            Likes Received:
            270
            Joined:
            Dec 28, 2020
            Location:
            Nevada
            Local Time:
            11:49 AM
            Got it
            My mistake

          • 66Satellite47

            66Satellite47 FBBO Gold Member FBBO Gold Member

            Messages:
            4,619
            Likes Received:
            3575
            Joined:
            Jan 15, 2015
            Location:
            St Paul MN
            Local Time:
            12:49 PM
            My bet, it would take an extremely capable welder, but those folks still amaze me.

            • Agree Agree x 1
            • Fran Blacker

              Fran Blacker FBBO Gold Member FBBO Gold Member

              Messages:
              9,288
              Likes Received:
              8915
              Joined:
              Sep 23, 2016
              Location:
              Connecticut
              Local Time:
              2:49 PM
              Get a junk piece for a welder to try it. He won't get a second try on your piece if he's wrong.

            • AR67GTX

              AR67GTX Well-Known Member

              Messages:
              1,572
              Likes Received:
              764
              Joined:
              Jan 28, 2012
              Location:
              Arkansas
              Local Time:
              1:49 PM
              Well, I think ultimately the question will need to be answered by a trim restoration business. I doubt most commercial welding shops would be equipped or willing to try it. Rather than calling or emailing a bunch of trim shops, I thought I would fish around here a little in hopes someone might have had similar experience with such work which could indicate if it’s feasible. And maybe even a place that could do it. I’ve actually stripped, repaired and polished a fair amount of aluminum trim but I haven’t run into a piece split like this before.

            • yella71

              yella71 Well-Known Member

              Messages:
              1,165
              Likes Received:
              1625
              Joined:
              Dec 18, 2018
              Location:
              nj
              Local Time:
              2:49 PM
              check out muggy weld

            • sam dupont

              sam dupont Well-Known Member

              Messages:
              214
              Likes Received:
              267
              Joined:
              Nov 9, 2020
              Location:
              USA
              Local Time:
              12:49 PM
              Pot metal can be welded, I have seen it done. The welder took a similar part, melted a chunk, and poured it into a piece of angle iron to create a welding rod. He then used a TIG rig to weld it up, with a Lincoln SA200 gas welder no less. Working on a lignite gasification plant, he made a number of TIG root passes on stainless pipe that were 1/64th of an inch across.
              He claimed he could weld anything except a broken heart or the crack of doom. I challenged him and he welded that scrap pot metal to his 1/2 plate steel work bench. I had to pound with a hammer for a while to make it come loose. I thought it would pop right off, but it didn't.
              The thing about pot metal is the mix in the pot is different every day. Difficult, often not successful, but it is possible.

            • Photon440

              Photon440 FBBO Gold Member FBBO Gold Member

              Messages:
              10,950
              Likes Received:
              11496
              Joined:
              Mar 14, 2012
              Location:
              Surrey, B.C. Canada
              Local Time:
              11:49 AM
              Welding really thin aluminum isn't easy. But check out aluminum solder. They fix a hole in a Pepsi can in this video.


              ps. I've used aluminum solder to patch a hole that was worn through an air conditioning line.

              Last edited: Jan 20, 2021
              • Thanks! Thanks! x 2
              • Agree Agree x 1
              • 451Mopar

                451Mopar Well-Known Member

                Messages:
                2,358
                Likes Received:
                1702
                Joined:
                Oct 25, 2011
                Location:
                Aurora, CO
                Local Time:
                12:49 PM
                soldering sounds easier?
                welding thin metal is a matter of scale.
                You would need a really small diameter tungsten electrode about the thickness of the aluminum trim (0.020"?), and a tig that can be set to a pretty low amperage like 15 amps?

              • AR67GTX

                AR67GTX Well-Known Member

                Messages:
                1,572
                Likes Received:
                764
                Joined:
                Jan 28, 2012
                Location:
                Arkansas
                Local Time:
                1:49 PM
                Not pot metal.

              • 1967coronet

                1967coronet FBBO Gold Member FBBO Gold Member

                Messages:
                2,766
                Likes Received:
                3316
                Joined:
                Jun 19, 2014
                Location:
                Iowa
                Local Time:
                1:49 PM
                Seen the same basic stuff at a swap meet, guy selling was fixing soda, beer cans and selling rod.
                Keep searching OP, that aluminum rod is available.
