what carb should i use on the new 496 stroker eng

Resto-Mods & Pro-Touring forum

  1. JNBowen

    JNBowen Member

    Messages:
    15
    Likes Received:
    7
    Joined:
    May 20, 2015
    Location:
    Yuma, AZ
    Local Time:
    6:38 AM
    Ok looking for your thoughts, I am working on my 68 charger just pulled the tired old 440 that was a band aid for the car while the 383 was being built. I am nearing completion and want to put the most carb I can on the old girl with out putting to much. So what I have is a 383 block .60 over 440 source balanced stroker kit. 440 source aluminum heads with the upgraded valve springs and seats. Roller rockers from 440 source again. Pro comp cam .545 lift 110 degree lobe separation. Edlebrock high rise single plain entake. MSD Ready to run distributor. I still have to get plugs and a carb because I just dont think the holley 670 is going ot cut it. The engine builder said I need a medium heat spark plug (not sure what that means) but anyway I need ideas for the right carburetor. Keep in mind the ready to run distributor has a vaccum advance and the hide away head lights also use vaccum to open. I have heard of people using a cable to open those but never actually seen it. The one wrapped up is the 383/496. Please shoot me some ideas I dont want it to be limited by the carb but I dont want to get more than I need.

    11047119_10200164158023245_474728419_n.jpg 11212223_10200330234095043_390872286_n.jpg


    Attached Files:

  2. Mike Gaines

    Mike Gaines Well-Known Member

    Messages:
    1,914
    Likes Received:
    3760
    Joined:
    Apr 17, 2014
    Location:
    Ahwahnee, (Fresno) California
    Local Time:
    5:38 AM
    I would get an 850CFM Demon. I bought one for my 505" (850 Mighty Demon) and just love it. It is easy to set the idle also without disturbing the "slot" setting in the butterflies. Check them out on Summit...or better yet...just call Demon and ask them for a recommendation. I love the carb.

    • Like Like x 1
    • Xp29h

      Xp29h FBBO Gold Member FBBO Gold Member

      Messages:
      4,247
      Likes Received:
      3791
      Joined:
      Aug 9, 2013
      Location:
      Maine
      Local Time:
      8:38 AM
      There could be a few options for you. My recommendation is spend the bucks and buy new no matter which way you go. This could get costly though until you find the right combo.

      I'm running an 850 Holley on my mildly modded 383. It doesn't pull good in early rpm range but I haven't found top end yet. But, the motor has some issues and currently stoking a 400 with the 440source 512 kit. I will start with the same 850.

      Good luck!

      • Like Like x 1
      • Dennis H

        Dennis H FBBO Gold Member FBBO Gold Member

        Messages:
        13,431
        Likes Received:
        15990
        Joined:
        Jul 11, 2010
        Location:
        San Jose
        Local Time:
        7:38 AM
        I too like the 850 Mighty Demon. NGK plugs work well too.

        • Like Like x 1
        • theman440

          theman440 Well-Known Member

          Messages:
          1,398
          Likes Received:
          689
          Joined:
          Apr 21, 2011
          Location:
          Las Vegas
          Local Time:
          5:38 AM
          950 cfm

          • Like Like x 1
          • 72 Charger SE

            72 Charger SE Well-Known Member

            Messages:
            302
            Likes Received:
            28
            Joined:
            Jan 12, 2010
            Location:
            Pacific NW
            Local Time:
            5:38 AM
            I've got an 850 Speed Demon with electric choke that I might be persuaded to part with if you choose to go that route.

          • 65hemi

            65hemi Well-Known Member

            Messages:
            850
            Likes Received:
            1417
            Joined:
            May 21, 2011
            Location:
            Winnipeg, Manitoba
            Local Time:
            7:38 AM
            Holley 950 HP on mine.

            • Like Like x 1
            • uwss

              uwss Well-Known Member

              Messages:
              628
              Likes Received:
              175
              Joined:
              Sep 5, 2012
              Location:
              Dallas, Texas
              Local Time:
              7:38 AM
              Dyno will tell you ; so spend the extra bucks bring 3 or 4 carbs and try them out. You will need to adjust your timing also.

            • Budnicks

              Budnicks You Can Just Thank Me Latter

              Messages:
              48,856
              Likes Received:
              44383
              Joined:
              Jan 16, 2011
              Location:
              East of Sonora Calif., We love the 2nd Amendment
              Local Time:
              5:38 AM
              I personally Like Quickfuel Carbs & components the best for Holley type carbs

              IMO If the heads are going to be ported, you need a little bigger carb,
              then I personally would go with the HP 950 Holley
              any of the Holley style of carb form Quickfuel, AEM, Proform,
              even a Demon {owned by Holley Now}, Holley HP series, Promaxx
              none of them are cheap but well worth the extra $$$

              Id also highly suggest to get a couple books or dvds,
              to learn or "actually" know how to properly size & tune a Holley style carb too

              I'd also suggest getting a few different sizes up & down
              of accelerator pump discharge nozzles
              assorted colors acc. pump cams
              assorted sizes of main jets
              assorted power-valves
              {usually need about 1/2 the # of inches of vacuum, the engine makes at idle}
              Assorted gaskets for metering blocks, fuel bowls & secondary plates if vacuum

              I would also add that if you get a regular Holley 4bbl,
              to get better metering blocks, adj. emulsion tubes
              & air bleeds will help to fine tune your specific engines needs...
              If it's a vacuum sec. carbs style carb {great for a street driven automatic}
              I'd suggest to get a kit/set of assorted diaphragm springs,
              so to be able to change rate of opening...
              I'd also suggest if it's a vacuum sec. carb, getting adj. secondary plates,
              to use reg. Holley jets, from someone like Quickfuel or Promaxx etc.

              IMO If your not having the heads ported the HP 850cfm Holley will probably be fine,
              depend really what it is you want, what the end use will be, what are your expectations,
              any Holley style aftermarket supplier, would be a great choice, even then,
              it should still be fine tuned after installation, for your specific combo...
              Don't expect to have it be perfect out of the box, regardless who you get it from...

              CI x RPM dived by 3456 = CFM
              Example;
              496ci X 6000rpm/3456 = 861cfm
              496ci X 7000rpm/3456 = 1004cfm
              that formula is for about an 80% efficient set up,
              which is pretty good for non ported heads,
              for a race motor or spinning higher RPMs &
              getting the most flow capable out of it & ported heads a little more carb is probably better...

              It depend really how it's going to be used ?
              what rpm's you run ?
              what type of trans &/or converter ?
              what camshaft ?
              what altitudes ?
              what gears ?
              what head work & cfm flow rate ?
              what weight of car ?
              there's allot of other factors to consider


              Attached Files:

              Last edited: Jun 6, 2015
              • Like Like x 2
              • JNBowen

                JNBowen Member

                Messages:
                15
                Likes Received:
                7
                Joined:
                May 20, 2015
                Location:
                Yuma, AZ
                Local Time:
                6:38 AM
                Thanks you for taking the time to add so much info I will definately take all this into account. I am leaning towards the 850 cfm. Holley or quick fuel. That formula is awesome. Again thanks for the detailed response. I never realized people were so helpful on these forums.

                • Like Like x 1
                • Car Nut

                  Car Nut Well-Known Member

                  Messages:
                  33,110
                  Likes Received:
                  77802
                  Joined:
                  Dec 6, 2012
                  Location:
                  Zombieland
                  Local Time:
                  6:38 AM
                  I have a Holley 750 DP on my stock 383, so a Holley 850 DP would be perfect on yours.

                  Have you thought about a six pack set up for your 383?

                • JNBowen

                  JNBowen Member

                  Messages:
                  15
                  Likes Received:
                  7
                  Joined:
                  May 20, 2015
                  Location:
                  Yuma, AZ
                  Local Time:
                  6:38 AM
                  NO i have not considered it just do to the complex nature and the added expense. Only because I am not going for a stock look and I figure the 850 to 1050 cfm would out perform the six pack but again that is just my lack of knowledge of the six packs. Very cool just not something I had considered

                • Rocketman

                  Rocketman Well-Known Member

                  Messages:
                  548
                  Likes Received:
                  231
                  Joined:
                  May 12, 2013
                  Location:
                  Kentucky
                  Local Time:
                  7:38 AM
                  I have a Holley 3310 750 cfm on a modified 440 ground to .060 over. Edelbrock top end kit, Comp .545 lift cam, and MSD ignition. It is the perfect carb for me. My dyno tuner says ideally a 770 cfm would be best if I was racing, but this is a street machine. He said 850 cfm would waste money and fuel.

                • 5.7 hemi

                  5.7 hemi FBBO Gold Member FBBO Gold Member

                  Messages:
                  12,032
                  Likes Received:
                  8500
                  Joined:
                  Dec 21, 2008
                  Location:
                  ca
                  Local Time:
                  7:38 AM
                  Fuel injection....nough' said!

                • 747mopar

                  747mopar Well-Known Member

                  Messages:
                  11,323
                  Likes Received:
                  12717
                  Joined:
                  Oct 30, 2012
                  Location:
                  ohio
                  Local Time:
                  7:38 AM
                  I'm running an 850 Street Demon DP on my 456" and like it, there are better ones with more tuning options like the mentioned QuickFuel but I just feel the Demons are the best bang for the buck at $450.00ish. I personally won't run a carb without a choke (takes 2 people to start the car in cool temps haha) so that's why I run the Street Demon and buy the choke kit.

                • 65Fury440

                  65Fury440 Well-Known Member

                  Messages:
                  234
                  Likes Received:
                  194
                  Joined:
                  Jan 1, 2014
                  Location:
                  Fl
                  Local Time:
                  8:38 AM
                  I have an 850 Mighty Demon with annular boosters and love it.
